NSN 2040-01-606-2447 H5041B , 01-606-2447, 016062447
Product Details | VENTILATION DUCT TERMINAL
2040-01-606-2447 A fabricated device, generally constructed with a flared end and a straight or elbow type body. It may contain a damper and is designed to be used at the end of a ventilating duct to control the quantity and/or the direction of air flow.205156000001680000020400030Marine Hardware and Hull Items45200033Space and Water Heating Equipment56700034Building Components, Prefabricated
Part Alternates: H5041B , 2040-01-606-2447, 01-606-2447, 2040016062447, 016062447
Ship and Marine Equipment | Marine Hardware and Hull Items
Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
---|---|---|---|
20 | 2012135 | 01-606-2447 | 15042 ( TERMINAL, VENTILATION DUCT ) |
Demand History | NSN 2040-01-606-2447
Part Number | Request Date | QTY | Origin |
---|---|---|---|
H5041B | 2023-10-299 | 114 | DIBBS |
H5041B | 2023-08-229 | 29 | DIBBS |
H5041B | 2022-02-46 | 29 | DIBBS |
H5041B | 2021-10-284 | 29 | DIBBS |
H5041B | 2021-08-216 | 29 | DIBBS |
H5041B | 2020-02-44 | 42 | DIBBS |
2040-01-606-2447 | 2017-10-304 | 13 | DIBBS |
2040-01-606-2447 | 2017-10-292 | 4 | DIBBS |
2040-01-606-2447 | 2014-12-359 | 8 | DIBBS |
Cross Reference | NSN 2040-01-606-2447
Part Number | Cage Code | Manufacturer |
---|---|---|
H5041B | 1VXE0 | HEATERCRAFT MARINE PRODUCTS INC |
Request a Quote
What Our Customers Say
Compare
NSNs for Compare ( up to 4 ): Add 2040-01-606-2447
Related Products | NSN 2040-01-606-2447
Technical Data | NSN 2040-01-606-2447
Characteristic | Specifications |
---|---|
OVERALL LENGTH | 3.0 INCHES NOMINAL |
OVERALL DIAMETER | 3.9 INCHES NOMINAL |
III END ITEM IDENTIFICATION | BOAT UTILITY MPF |
Restrictions/Controls & Freight Information | NSN 2040-01-606-2447
Category | Code | Description |
---|---|---|
Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
Electro-static Discharge Susceptible: | A | No known Electrostatic Discharge (ESD) or Electromagnetic Interference (EMI) sensitivity |
Precious Metals Indicator Code: | A | Item does not contain precious metal |
Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
Category | Code | Description |
---|---|---|
NMF Description | 051035 | DUCTS:AIR SYSTEM |
Less than car load rating | ||
Less than truck load rating | W | Rating Variable |
Water commodity Code | 810 | unknown |
Originating Activity Code | HD | Naval Inventory Control Point Mechanicsburg, PA 17055-0788 |
Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
Air Commodity | N | Ship's parts. |
Air Special Handling | Z | No special handling required. |
Special Handling Code | 9 | unknonwn |
HAZMAT | ||
Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 2040-01-606-2447
Category | Code | Description |
---|---|---|
Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
Agency | DN | Department of the Navy |
Service Organization | N | U.S. Navy |
Acquisition Advice Codes | J | NOT STOCKED, CENTRALLY PROCURED # (NON-STOCKED ITEMS) IMM/Service centrally managed but not stocked item. Procurement will be initiated only after receipt of a requisition. |
Controlled Item Code | U | UNCLASSIFIED |
Shelf Life Code | 0 | Nondeteriorative |
Purchasing | QTY UOM |
1 EA : Each |
