Product Details | GROUND HANDLING EQUIPMENT CRADLE

1730-01-496-3333 A cradle designed to hold an aircraft component and used in conjunction with lift trucks, trailers and the like. It is generally used to transport aircraft components to/from the maintenance shops and to hold them during repair. Excludes items having a more specific name.

Part Alternates: GSU-367/E, GSU367E, 3637AS600, 3637AS6001, 3637AS600-1, 1730-01-496-3333, 01-496-3333, 1730014963333, 014963333

2540 | Aircraft Ground Servicing Equipment

Supply Group (FSG) NSN Assign. NIIN
25 11 APR 2002 01-496-3333

Demand History | NSN 1730-01-496-3333

Part Number Request Date QTY Origin
1730-01-496-3333 2023-12-341 1 US

Cross Reference | NSN 1730-01-496-3333

Part Number Cage Code Manufacturer
3637AS600 30003 NAVAL AIR SYSTEMS COMMAND
3637AS600-1 53247 PRODUCTS SUPPORT, INC.
GSU-367/E 07878 AERONAUTICAL AND SUPPORT EQUIPMENT TYPE DESIGNATION SYSTEM /ASETDS/

Request a Quote

What Our Customers Say

Compare

NSNs for Compare ( up to 4 ): Add 1730-01-496-3333

Technical Data | NSN 1730-01-496-3333

Characteristic Specifications
MATERIAL ALUMINUM ALLOY OR STEEL, CORROSION RESISTING
FABRICATION METHOD BOLTED OR RIVETED
TRANSPORT METHOD MANUALLY CARRIED
OVERALL LENGTH 96.000 INCHES NOMINAL
OVERALL WIDTH 46.500 INCHES NOMINAL
OVERALL HEIGHT 40.750 INCHES NOMINAL
SPECIAL FEATURES DOLLY ASSY HAS ALL ITEMS FOR COMPLETED HANDLING UNIT
CRITICALITY CODE JUSTIFICATION ATJP
III PART NAME ASSIGNED BY CONTROLLING AGENCY DOLLY,HANDLING,GSU-367/E

Restrictions/Controls & Freight Information | NSN 1730-01-496-3333

Category Code Description
Shelf-Life Code:0Nondeteriorative
Hazardous Material Indicator CodeNThere is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials
Demilitarization Code:BMunitions List Item - Mutilation (MUT) to the point of scrap required. (Formerly: Demilitarization not required. Trade Security Controls (TSCs) required at disposition.)
Controlled Inventory Item Code:UUNCLASSIFIED
Precious Metals Indicator Code:AItem does not contain precious metal
Criticality Code:YThe item does not have a nuclear hardened feature but does have other critical feature(s) such as tolerance, fit restriction or application.
Automatic Data Processing Equipment:0Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9)
Category Code Description
NMF Description 095142 HARDWARE HANDLES,IRON/STEEL
Less than car load rating Q 70
Less than truck load rating Q 70.0
Water commodity Code 576 unknown
Originating Activity Code KE Naval ICP
Philadelphia, PA 19111
Air Dimension Code A Shipment is not a consolidation and does not exceed 72 inches in any dimension.
Air Commodity
Air Special Handling Z No special handling required.
Special Handling Code 9 unknonwn
HAZMAT
Type of Cargo Z No special type of cargo code applicable

Management | NSN 1730-01-496-3333

Category Code Description
Cognizance Codes6RAeronautical ground support equipment (reparable or investment type material)
Naval Inventory Control Point, Philadelphia
Special Material IDQFFIGHTERAIRCRAFT(F18 E/F)
Issue Repair, or RequisitionBSSubmit/refer requisitions to NAVICP PHIL.
Special Material Content9 Non-Hazardous or Non-Sensitive Item, does not require hazardous or special handling, packaging or precautions
Source of SupplyNRPNAVICP-ERP
700 Robbins Avenue
Philadelphia, PA 19111-5098
AgencyDNDepartment of the Navy
Service OrganizationLLead Service - 22 (Repairable)
ReparabilityXSpecial Program Reparables
Acquisition Advice CodesJNOT STOCKED, CENTRALLY PROCURED # (NON-STOCKED ITEMS) IMM/Service centrally managed but not stocked item. Procurement will be initiated only after receipt of a requisition.
Controlled Item CodeUUNCLASSIFIED
Shelf Life Code0Nondeteriorative
Purchasing QTY
UOM
1
EA : Each
