NSN 1730-00-013-8813 MHU104E, MHU-104E, PDG2172
Product Details | AIRCRAFT LANDING GEAR JACK
1730-00-013-8813 A lifting device which consists basically of a ram(s) actuated by a hydraulic pump(s). One end of the ram(s) is designed specifically to mate with the jacking points on the landing gear of an aircraft. It may have a wheeled base with a drawbar for mobility. Excludes JACK, DOLLY TYPE, HYDRAULIC and JACK, HYDRAULIC, HAND.
Part Alternates: MHU104E, MHU-104E, PDG2172, 24340001, 2434000-1, 1730-00-013-8813, 00-013-8813, 1730000138813, 000138813
2540 | Aircraft Ground Servicing Equipment
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 25 | 03 MAY 1968 | 00-013-8813 | 26862 ( JACK, AIRCRAFT LANDING GEAR ) |
Demand History | NSN 1730-00-013-8813
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 1730-00-013-8813 | 2023-09-256 | 1 | United States |
| 1730-00-013-8813 | 2021-09-264 | 1 | ID |
| 1730-00-013-8813 | 2020-06-171 | 1 | US |
| 1730-00-013-8813 | 2020-06-169 | 1 | SA |
| 1730-00-013-8813 | 2020-02-56 | 2 | us |
| 1730-00-013-8813 | 2019-12-357 | 1 | United States |
| 1730-00-013-8813 | 2019-09-248 | 1 | US |
| 1730-00-013-8813 | 2019-08-222 | 1 | US |
| 1730-00-013-8813 | 2019-06-177 | 1 | United States |
| 1730-00-013-8813 | 2018-04-114 | 1 | SG |
| 1730-00-013-8813 | 2017-01-12 | 2 | Poland |
| PDG2172 | 2015-09-251 | 1 | US |
| 1730-00-013-8813 | 2007-04-100 | 2 | Spain |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 1730-00-013-8813
Related Products | NSN 1730-00-013-8813
Technical Data | NSN 1730-00-013-8813
| Characteristic | Specifications |
|---|---|
| DESIGN TYPE | SELF-CONTAINED |
| MOVEMENT TYPE | MOBILE |
| BASE SHAPE | RECTANGULAR |
| RATED VERTICAL CAPACITY | 15.0 TONS |
| RETRACTED HEIGHT | 21.000 INCHES |
| EXTENDED HEIGHT | 21.000 INCHES |
| SCREW EXTENSION | NOT INCLUDED |
| PUMP TYPE AND QUANTITY | 1 HAND |
| POWER OPERATED PUMP MOUNTING PROVISION | NOT PROVIDED |
| PUMP RELATIONSHIP TO LIFTING DEVICE | INTEGRAL |
| WHEEL REMOVAL CRANE | NOT INCLUDED |
| TIRE ACCOMMODATION OUTSIDE DIAMETER | 4.000 INCHES MINIMUM AND 36.000 INCHES MAXIMUM |
| LOAD CAPACITY | 30000.0 POUNDS |
| SPECIAL FEATURES | CONTAINS PINTLE HOOK; 360 DEG CASTERS WITH 12 IN DIA WHEELS |
| III END ITEM IDENTIFICATION | F-16A/B/C/D |
| III FUNCTIONAL DESCRIPTION | USED TO ASSIST IN REMOVAL OF DISABLED AIRCRAFT FROM ACTIVE RUNWAY AREA |
| III TYPE/MODEL DESIGNATION | MHU-104/E |
| III REFERENCE DATA AND LITERATURE | T.O.35D3-32-3-1 |
Restrictions/Controls & Freight Information | NSN 1730-00-013-8813
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 157520 | PLATFORMS AIRCRAFT CARGO SHIPNG NOI |
| Less than car load rating | ||
| Less than truck load rating | Q | 70.0 |
| Water commodity Code | 671 | unknown |
| Originating Activity Code | SE | San Antonio Air Logistics Center Kelly AFB, TX 78241-5000 |
| Air Dimension Code | Z | Shipment is not a consolidation, but does exceed 72 inches in one or more dimensions. |
| Air Commodity | ||
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | R | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 1730-00-013-8813
Air Force
Navy| Category | Code | Description |
|---|---|---|
| Price Validation | N | The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
|
| Materiel Management Aggregation Code | RN | TG:GROUND SUPPORT EQUIPMENT (FSC RESIDUAL MMAC) |
| Budget Code | Y | variousO & M:AF centrally procured equipment items. They are separate, primary end items (other than the weapon system itself) needed by a user to perform an assigned mission. They are nonexpendable items (ERRCD NF or ND) which are not consumed in use, and they do not lose their original identity during periods of use by incorporation into, or attachment to another assembly. |
| Source of Supply | FLZ | Warner Robins Air Logistics Center Robins AFB, GA 31098-5609 |
| Agency | DF | Department of the Air Force |
| Service Organization | L | Lead Service - 22 (Repairable) |
| Reparability | U | AF Equipment Management System (AFEMS) |
| Acquisition Advice Codes | V | TERMINAL ITEM # Identifies items in stock, but future procurement is not authorized. Requisitions may continue to be submitted until stocks are exhausted. Preferred item National Stock Number is normally provided by application of the phrase: When Exhausted Use (NSN). Requisitions will be submitted in accordance with IMM/Service requisitioning procedures as applicable. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 6R | Aeronautical ground support equipment (reparable or investment type material) Naval Inventory Control Point, Philadelphia |
| Issue Repair, or Requisition | BS | Submit/refer requisitions to NAVICP PHIL. |
| Special Material Content | 9 | Non-Hazardous or Non-Sensitive Item, does not require hazardous or special handling, packaging or precautions |
| Source of Supply | NRP | NAVICP-ERP 700 Robbins Avenue Philadelphia, PA 19111-5098 |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Reparability | X | Special Program Reparables |
| Acquisition Advice Codes | J | NOT STOCKED, CENTRALLY PROCURED # (NON-STOCKED ITEMS) IMM/Service centrally managed but not stocked item. Procurement will be initiated only after receipt of a requisition. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
