NSN 1680-01-016-3465 1444T1007, 1444T100-7, 673119-107
Product Details | ROTARY ELECTRO-MECHANICAL ACTUATOR
1680-01-016-3465 A self-contained power transmitting device designed to convert electrical energy into controlled mechanical force, in the form of torque (rotational mechanical movement). Comprised of an electric motor(s), gear box(es), limit switch(es), and such accessories as required for the specific moving and positioning of other components. Excludes hydraulic and pneumatic cylinders and screwjacks.21212700040Aircraft Gunnery Fire Control Components14200025Guided Missile Components14400025Launchers, Guided Missile1675000016800049Miscellaneous Aircraft Accessories and Components18200024Space Vehicle Components29100042Engine Fuel System Components, Nonaircraft29150064Engine Fuel System Components, Aircraft and Missile Prime Movers30100036Torque Converters and Speed Changers4130000048100015Valves, Powered49200058Aircraft Maintenance and Repair Shop Specialized Equipment
Part Alternates: 1444T1007, 1444T100-7, 673119-107, 1680-01-016-3465, 01-016-3465, 1680010163465, 010163465, 673119107
Aircraft Components and Accessories | Miscellaneous Aircraft Accessories and Components
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 16 | 01-016-3465 | 11006 ( ACTUATOR, ELECTRO-MECHANICAL, ROTARY ) |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 1680-01-016-3465
Technical Data | NSN 1680-01-016-3465
| Characteristic | Specifications |
|---|---|
| CURRENT TYPE | AC |
| VOLTAGE IN VOLTS | 115.0 AND 200.0 |
| FREQUENCY IN HERTZ | 400.0 |
| PHASE | THREE |
| CURRENT RATING IN AMPS | 2.5 |
| DUTY CYCLE | CONTINUOUS |
| SHAFT ROTATION DIRECTION | CLOCKWISE |
| DRIVE TYPE | FRICTION |
| BRAKING METHOD | ELECTRIC |
| LIMIT SWITCH CONTROL | NOT INCLUDED |
| MANUAL OVERRIDE | NOT INCLUDED |
| TERMINAL TYPE | CONNECTOR |
| BODY LENGTH | 15.000 INCHES NOMINAL |
| MANUFACTURERS CODE | 98889 |
| DESIGN CONTROL REFERENCE | 1444T100-7 |
Restrictions/Controls & Freight Information | NSN 1680-01-016-3465
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Category | Code | Description |
|---|---|---|
| No Freight Information | ||
