NSN 1680-00-924-5301 02312-0034-0001, 2312M341, 2312M-34-1
Product Details | FLEXIBLE SHAFT ASSEMBLY
1680-00-924-5301 An item consisting of a casing with fittings and attachments on each end and a spirally wound wire core with formed end(s) and/or crimped on end fittings. It is designed to transmit rotary motion around bends from a motor or other power source to drive various types of equipment, such as tachometers, speedometers, remote controls, instruments, and the like, which are located at an angle and/or distance from the power source. See also CONTROL ASSEMBLY, PUSH-PULL.20316800049Miscellaneous Aircraft Accessories and Components30400042Miscellaneous Power Transmission Equipment66800078Liquid and Gas Flow, Liquid Level, and Mechanical Motion Measuring Instruments
Part Alternates: 02312-0034-0001, 2312M341, 2312M-34-1, 1680-00-924-5301, 00-924-5301, 0231200340001, 1680009245301, 009245301
Aircraft Components and Accessories | Miscellaneous Aircraft Accessories and Components
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 16 | 28 JAN 1966 | 00-924-5301 | 20315 ( SHAFT ASSEMBLY, FLEXIBLE ) |
Demand History | NSN 1680-00-924-5301
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 1680-00-924-5301 | 2017-05-129 | 14 | DIBBS |
| 1680-00-924-5301 | 2016-02-55 | 38 | DIBBS |
| 1680-00-924-5301 | 2016-01-10 | 28 | DIBBS |
| 1680-00-924-5301 | 2015-12-354 | 8 | DIBBS |
| 1680-00-924-5301 | 2015-01-11 | 20 | DIBBS |
| 1680-00-924-5301 | 2014-02-54 | 12 | DIBBS |
| 1680-00-924-5301 | 2013-08-213 | 6 | DIBBS |
| 1680-00-924-5301 | 2012-09-262 | 6 | DIBBS |
| 1680-00-924-5301 | 2012-05-126 | 7 | DIBBS |
| 1680-00-924-5301 | 2011-09-244 | 9 | DIBBS |
| 1680-00-924-5301 | 2011-01-25 | 2 | US |
| 1680-00-924-5301 | 2008-05-128 | 39 | DIBBS |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 1680-00-924-5301
Related Products | NSN 1680-00-924-5301
Technical Data | NSN 1680-00-924-5301
| Characteristic | Specifications |
|---|---|
| CASING MATERIAL | PHOSPHOR BRONZE |
| CASING LENGTH BETWEEN FERRULES | 19.253 INCHES NOMINAL |
| CASING OUTSIDE DIAMETER | 0.317 INCHES NOMINAL |
| CASING PROTECTIVE DEVICE TYPE | COILED SPRING PROTECTOR |
| END CONNECTION TYPE | PLAIN FERRULE BOTH ENDS |
| END OVERALL DIAMETER | 0.563 INCHES NOMINAL BOTH ENDS |
| SHANK OUTSIDE DIAMETER | 0.406 INCHES NOMINAL BOTH ENDS |
| FLANGE THICKNESS | 0.904 INCHES NOMINAL BOTH ENDS |
| SWIVEL END | NOT PROVIDED BOTH ENDS |
| WRENCHING FACILITY TYPE | HEXAGON BOTH ENDS |
| WIDTH ACROSS FLATS | 0.750 INCHES NOMINAL BOTH ENDS |
| LUBRICATION FITTING | NOT PROVIDED BOTH ENDS |
| CORE MATERIAL | NICKEL COPPER ALLOY |
| CORE OVERALL LENGTH | 20.190 INCHES NOMINAL |
| CORE DIAMETER | 0.187 INCHES NOMINAL |
| CORE ROTATION DIRECTION | CLOCKWISE |
| END TYPE | SQUARE MALE BOTH ENDS |
| TIP LENGTH | 0.4062 INCHES NOMINAL BOTH ENDS |
| CROSS SECTION SIZE AND LOCATION | 0.151 INCHES MINIMUM ACROSS FLATS FIRST END 0.154 INCHES MAXIMUM ACROSS FLATS SECOND END |
| SETSCREW | NOT INCLUDED BOTH ENDS |
| CORE REMOVABILITY | NONREMOVABLE |
| OVERALL LENGTH | 21.002 INCHES NOMINAL |
| TORSIONAL DEFLECTION RATING | NOT RATED |
| MINIMUM OPERATING RADIUS | 6.000 INCHES |
| III FSC APPLICATION DATA | WINDSHIELD WIPER INSTALLATION,AIRCRAFT |
| MANUFACTURERS CODE | 59885 |
| DESIGN CONTROL REFERENCE | 02312-0034-0001 |
Restrictions/Controls & Freight Information | NSN 1680-00-924-5301
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | Q | Strategic List Item (SLI). Demilitarization not required. SLI are non-MLI(Munitions List Items) controlled by the U.S. Dept. of Commerce through the Export Administration Regulations (EAR) and indicated on the Commerce Control List (CCL). Each CCL entry is preceded by a four-digit Export Control Commerce Control List Item (CCLI) – MUT to the point of scrap required outside the United States. Inside the United States, MUT is required when the DEMIL integrity code (IC) is “3” and MUT is not required when the DEMIL IC is “6.” |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 129920 | SHAFTS/SHAFTING,FLEX NOI STL |
| Less than car load rating | ||
| Less than truck load rating | M | 85.0 |
| Water commodity Code | 72D | unknown |
| Originating Activity Code | KE | Naval ICP Philadelphia, PA 19111 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | ||
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 1680-00-924-5301
Army
Air Force
Navy| Category | Code | Description |
|---|---|---|
| Materiel Category and Inventory Manager | J | Ground Forces Support Materiel (DLA/GSA Items) |
| Appropriation and Budget Activity | 2 | Stock Fund Secondary Items |
| Management Inventory Segment | 2 | NONREPARABLE ITEMS (Exclusive of Insurance and Provisioning Items). This code will be used to identify items which are not reparable. |
| Specific Group/Generic Code | 0 | Medical Materiel |
| Weapons Systems/End Item or Homogeneous Group | 00 | DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item |
| Accounting Requirements Code | X | Expendable item. An item of Army property coded with an ARC of ?X? in the AMDF. Expendable items require no formal accountability after issue from a stock record account. Commercial and fabricated items similar to items coded ?X? in the AMDF are considered expendable items. |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DA | Department of the Army |
| Service Organization | A | U.S. Army |
| Reparability | A | Item requires special handling or condemnation procedures for specific reasons, such as precious metal content, high dollar value, critical material, or hazardous materiel. Refer to appropriate manuals or directives for specific instructions. |
| Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
| Category | Code | Description |
|---|---|---|
| Budget Code | 9 | General Support DIV57X4921.070:Air Force decentrally managed expense items (ERRC XB3, XF-3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors. |
| Price Validation | N | The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
|
| Fund Code | SF | Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point. |
| Materiel Management Aggregation Code | SX | SX:AF SICA RESIDUAL MMAC-OC-ALC |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DF | Department of the Air Force |
| Service Organization | F | U.S. Air Force |
| Reparability | N | Stock Fund (except Munitions) |
| Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
