NSN 1680-00-517-8388 NAS77, NAS778030, NAS77-8-030
Product Details | AIRCRAFT INSTRUMENTS FILTER
1680-00-517-8388 An air filtering device designed to clean and dry the air flowing to the sensitive vacuum operated flight instruments in an aircraft.
Part Alternates: NAS77, NAS778030, NAS77-8-030 , NAS77830, NAS77-8-30 , AN58221, AN5822-1, JH3116, PA128, PA12-8, PA12, 12, 27300, 28668, 29797, 3116, 647984, 1680-00-517-8388, 00-517-8388, 1680005178388, 005178388
Aircraft Components and Accessories | Miscellaneous Aircraft Accessories and Components
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 16 | 01 JAN 1963 | 00-517-8388 | 05190 ( FILTER, AIRCRAFT INSTRUMENTS ) |
Demand History | NSN 1680-00-517-8388
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| NAS778030 | 2024-06-165 | 4 | United States |
| NAS778030 | 2024-03-82 | 4 | United States |
| 12 | 2020-03-84 | 0 | United States |
| NAS778030 | 2016-04-102 | 25 | US |
| 1680-00-517-8388 | 2014-09-255 | 1 | CO |
| 28668 | 2011-08-228 | 15 | DE |
| AN58221 | 2008-07-212 | 1 | Philippines |
| 1680-00-517-8388 | 2008-06-164 | 1 | United States |
| AN58221 | 2008-02-45 | 1 | US |
| NAS778030 | 2007-03-67 | 300 | United States |
Cross Reference | NSN 1680-00-517-8388
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 12 | 05779 | PARKER-HANNIFIN CORPORATION DBA HYDRAULIC FILTER DIV |
| 12 | 45681 | PARKER-HANNIFIN CORPORATION DIV CORPORATE HEADQUARTERS |
| 27300 | 06840 | BENDIX CORP THE |
| 27300 | 14892 | BENDIX CORP THE BRAKE AND STEERING DIV |
| 27300 | 90005 | PUROLATOR FACET, INC. |
| 28668 | 64829 | ARVINMERITOR INC |
| 29797 | 64829 | ARVINMERITOR INC |
| 3116 | 31435 | LUCAS AEROSPACE POWER EQUIPMENT CORPORATION |
| 3116 | 3CPE0 | SAFRAN POWER USA, LLC |
| 647984 | 56232 | LOCKHEED MARTIN CORPORATION DBA LOCKHEED MARTIN |
| 647984 | 71995 | DRESSER INDUSTRIES INC WAUKESHA ENGINE DIV |
| AN5822-1 | 88044 | AERONAUTICAL STANDARDS GROUP DEPT OF NAVY AND AIR FORCE |
| JH3116 | 86887 | SIGMA TEK, INC. |
| PA12 | 64829 | ARVINMERITOR INC |
| PA12-8 | 64829 | ARVINMERITOR INC |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 1680-00-517-8388
Related Products | NSN 1680-00-517-8388
Technical Data | NSN 1680-00-517-8388
| Characteristic | Specifications |
|---|---|
| FILTRATION RATE | 10.000 CUBIC FEET PER MINUTE NOMINAL |
| MAXIMUM OPERATING PRESSURE | NOT RATED |
| FILTERING MATERIAL TYPE | ANY ACCEPTABLE |
| OVERALL LENGTH | 5.562 INCHES NOMINAL |
| OVERALL WIDTH | 5.344 INCHES NOMINAL |
| OVERALL THICKNESS | 2.812 INCHES NOMINAL |
| ATTACHING POINT QUANTITY | 2 |
| ATTACHMENT TYPE | HOLE |
| INLET OPENING SIZE | 3/4 IN. |
| INLET SCREEN NUMBER | 12 |
| INLET THREAD SERIES DESIGNATOR | ANPT |
| OUTLET OPENING SIZE | 3/4 IN. |
| OUTLET THREAD SERIES DESIGNATOR | ANPT |
Restrictions/Controls & Freight Information | NSN 1680-00-517-8388
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 115620 | BUSHINGS NOI I/S |
| Less than car load rating | ||
| Less than truck load rating | R | 65.0 |
| Water commodity Code | 742 | unknown |
| Originating Activity Code | XX | |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | V | Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 1680-00-517-8388
Army
Air Force
Navy| Category | Code | Description |
|---|---|---|
| Materiel Category and Inventory Manager | T | Industrial Supplies (DLA/GSA Items) |
| Appropriation and Budget Activity | 2 | Stock Fund Secondary Items |
| Management Inventory Segment | 2 | NONREPARABLE ITEMS (Exclusive of Insurance and Provisioning Items). This code will be used to identify items which are not reparable. |
| Specific Group/Generic Code | 0 | Medical Materiel |
| Weapons Systems/End Item or Homogeneous Group | 00 | DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item |
| Accounting Requirements Code | X | Expendable item. An item of Army property coded with an ARC of ?X? in the AMDF. Expendable items require no formal accountability after issue from a stock record account. Commercial and fabricated items similar to items coded ?X? in the AMDF are considered expendable items. |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DA | Department of the Army |
| Service Organization | A | U.S. Army |
| Reparability | Z | This is a nonreparable item. If condemned or economically unserviceable, then dispose at the level authorized replace the item. |
| Acquisition Advice Codes | D | DoD INTEGRATED MATERIEL-MANAGED, STOCKED, AND ISSUED # Issue, transfer, or shipment is not subject to specialized controls other than those imposed by the Integrated Materiel Manager/Service supply policy. 1. The item is centrally managed, stocked, and issued. 2. Requisitions must contain the fund citation required to acquire the item. Requisitions will be submitted in accordance with Integrated Materiel Manager(IMM)/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
| Category | Code | Description |
|---|---|---|
| Budget Code | 9 | General Support DIV57X4921.070:Air Force decentrally managed expense items (ERRC XB3, XF-3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors. |
| Fund Code | SF | Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point. |
| Price Validation | V | The current standard price has been validated.
|
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DF | Department of the Air Force |
| Service Organization | F | U.S. Air Force |
| Reparability | N | Stock Fund (except Munitions) |
| Acquisition Advice Codes | D | DoD INTEGRATED MATERIEL-MANAGED, STOCKED, AND ISSUED # Issue, transfer, or shipment is not subject to specialized controls other than those imposed by the Integrated Materiel Manager/Service supply policy. 1. The item is centrally managed, stocked, and issued. 2. Requisitions must contain the fund citation required to acquire the item. Requisitions will be submitted in accordance with Integrated Materiel Manager(IMM)/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | D | DoD INTEGRATED MATERIEL-MANAGED, STOCKED, AND ISSUED # Issue, transfer, or shipment is not subject to specialized controls other than those imposed by the Integrated Materiel Manager/Service supply policy. 1. The item is centrally managed, stocked, and issued. 2. Requisitions must contain the fund citation required to acquire the item. Requisitions will be submitted in accordance with Integrated Materiel Manager(IMM)/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
