NSN 1560-01-548-7841 1583102, 15831-02, 01-548-7841
Product Details | AIRCRAFT STIFFENER RIB
1560-01-548-7841 A vertical, relatively short, rib located in a fuselage, nacelle, pod, and the like. It follows the periphery and provides additional rigidity. It may join various components such as stringers, longerons, and the like. It is supplementary to the frames and blukheads. See also RIB (1), AIRFOIL.
Part Alternates: 1583102, 15831-02, 1560-01-548-7841, 01-548-7841, 1560015487841, 015487841
Aircraft and Airframe Structural Components | Airframe Structural Components
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 15 | 05 MAR 2007 | 01-548-7841 | 41027 ( RIB, STIFFENER, AIRCRAFT ) |
Demand History | NSN 1560-01-548-7841
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 1560-01-548-7841 | 2011-02-34 | 2 | NZ |
Cross Reference | NSN 1560-01-548-7841
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 15831-02 | 1M7R2 | CUB CRAFTERS, INC. |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 1560-01-548-7841
Technical Data | NSN 1560-01-548-7841
| Characteristic | Specifications |
|---|---|
| AIRCRAFT LOCATION | WING ASSEMBLY |
| SIDE FOR WHICH DESIGNED | BOTH SIDES |
| AIRCRAFT MISSION DESIGN SERIES | PA-18-150 |
| III END ITEM IDENTIFICATION | PIPER SUPER CUB AIRCRAFT, PA-18-150 |
Restrictions/Controls & Freight Information | NSN 1560-01-548-7841
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | Q | Strategic List Item (SLI). Demilitarization not required. SLI are non-MLI(Munitions List Items) controlled by the U.S. Dept. of Commerce through the Export Administration Regulations (EAR) and indicated on the Commerce Control List (CCL). Each CCL entry is preceded by a four-digit Export Control Commerce Control List Item (CCLI) – MUT to the point of scrap required outside the United States. Inside the United States, MUT is required when the DEMIL integrity code (IC) is “3” and MUT is not required when the DEMIL IC is “6.” |
| Electro-static Discharge Susceptible: | A | No known Electrostatic Discharge (ESD) or Electromagnetic Interference (EMI) sensitivity |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| No Freight Information | ||
