Product Details | AIRCRAFT FLUID MANIFOLD
1560-01-093-8121 An enclosure with three (3) or more openings designed for use in aircraft de-icing, fuel, hydraulic, oil, pneumatic, and vacuum systems to collect and/or distribute fluids. It may contain valves or metering devices and the like. Excludes MANIFOLD, AIRCRAFT INSTRUMENTS.20315600030Airframe Structural Components16300032Aircraft Wheel and Brake Systems29950042Miscellaneous Engine Accessories, Aircraft
Part Alternates: 70652-06254-043, 1560-01-093-8121, 01-093-8121, 1560010938121, 7065206254043, 010938121
Aircraft and Airframe Structural Components | Airframe Structural Components
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 15 | 25 APR 1980 | 01-093-8121 | 27020 ( MANIFOLD, FLUID, AIRCRAFT ) |
Drawings & Photos | NSN 1560-01-093-8121
Demand History | NSN 1560-01-093-8121
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 1560-01-093-8121 | 2018-11-318 | 3 | DIBBS |
| 7065-20-625-4043 | 2013-02-37 | 1 | Philippines |
Cross Reference | NSN 1560-01-093-8121
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 70652-06254-043 | 78286 | SIKORSKY AIRCRAFT CORPORATION |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 1560-01-093-8121
Related Products | NSN 1560-01-093-8121
Technical Data | NSN 1560-01-093-8121
| Characteristic | Specifications |
|---|---|
| CONNECTION QUANTITY | 4 |
| METERING VALVES | NOT PROVIDED |
| MATERIAL | ALUMINUM ALLOY, QQ-A-367, COMP 7075, T73 |
| MOUNTING HOLE QUANTITY | 4 |
| MOUNTING HOLE DIAMETER | 0.265 INCHES NOMINAL |
| MANUFACTURERS CODE | 78286 |
| DESIGN CONTROL REFERENCE | 70652-06254-043 |
Restrictions/Controls & Freight Information | NSN 1560-01-093-8121
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | B | Munitions List Item - Mutilation (MUT) to the point of scrap required. (Formerly: Demilitarization not required. Trade Security Controls (TSCs) required at disposition.) |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | F | The item is an Aviation Critical Safety Item/Flight Safety Critical Aircraft Part ((ACSI/FSCAP). |
| Category | Code | Description |
|---|---|---|
| NMF Description | 013120 | ALUMINUM ARTICLE NOI SUB 6 |
| Less than car load rating | J | 100.2 |
| Less than truck load rating | J | 100.2 |
| Water commodity Code | 671 | unknown |
| Originating Activity Code | CT | U.S. Army Aviation and Missile Command (AIR) Redstone Arsenal, AL 35898-5230 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | ||
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
