Product Details | AIRCRAFT STRUCTURAL PLATE
1560-00-758-3683 A flat or preformed item of metallic or nonmetallic material. It may vary in shape and its surface may be smooth and/or serrated. Its thickness is small in comparison to both its length and width. It is designed to be mounted upon a surface or between two surfaces. Its primary function is to strengthen, join, or separate aircraft structural parts. Excludes PLATE, MENDING; SHIM; and SPACER, PLATE.
Part Alternates: 204030990001, 204-030-990-001, 2040309901, 204-030-990-1, 1560-00-758-3683, 00-758-3683, 1560007583683, 007583683
Aircraft and Airframe Structural Components | Airframe Structural Components
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 15 | 01 JAN 1960 | 00-758-3683 | 31495 ( PLATE, STRUCTURAL, AIRCRAFT ) |
Drawings & Photos | NSN 1560-00-758-3683
Demand History | NSN 1560-00-758-3683
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 1560-00-758-3683 | 2017-09-269 | 116 | United States |
| 1560-00-758-3683 | 2017-07-201 | 116 | DIBBS |
| 1560-00-758-3683 | 2017-07-201 | 116 | DIBBS |
| 1560-00-758-3683 | 2017-05-131 | 82 | DIBBS |
| 1560-00-758-3683 | 2017-02-54 | 30 | DIBBS |
| 1560-00-758-3683 | 2016-05-152 | 18 | DIBBS |
| 1560-00-758-3683 | 2016-05-138 | 18 | DIBBS |
