Product Details | GRENADE LAUNCHER SIGHT

1005-01-560-6019 An aiming device consisting of a calibrated mounting plate to which is attached a sight bar assembly to provide an accurate angular measurement of elevation for firing a grenade.20310050018Guns, through 30mm10100026Guns, over 30mm up to 75mm10150024Guns, 75mm through 125mm

Part Alternates: 40L, 1005-01-560-6019, 01-560-6019, 1005015606019, 015606019

Weapons | Guns, through 30mm

Supply Group (FSG) NSN Assign. NIIN
10 05 FEB 2008 01-560-6019

Demand History | NSN 1005-01-560-6019

Part Number Request Date QTY Origin
40L 2018-09-261 5 United Arab Emirates
40L 2014-05-149 4 Sri Lanka

Cross Reference | NSN 1005-01-560-6019

Part Number Cage Code Manufacturer
40L 0N429 SAMSON MFG CO

Request a Quote

What Our Customers Say

Compare

NSNs for Compare ( up to 4 ): Add 1005-01-560-6019

Technical Data | NSN 1005-01-560-6019

Characteristic Specifications
GENERAL CHARACTERISTICS ITEM DESCRIPTION STANDALONE FLIP UP LOW REAR RIFLE SIGHT; SPRING LOADED, QUICK RELEASE LEVER PREVENTS ACCIDENTAL ENGAGING; 2 APERTURES; 250/300M; 500/600M; BUILT IN HORIZONTAL LINE FEATURE; FOR M4M16 RIFLES; TACTICAL OR BRUSH HUNTING; ELEVATION ZERO, FOLDS AWAY WHEN NOT IN USE

Restrictions/Controls & Freight Information | NSN 1005-01-560-6019

Category Code Description
Hazardous Material Indicator CodeNThere is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials
Demilitarization Code:DMunitions List Item or Commerce Control List Item. Demilitarization required. Total destruction of the item and components so as to preclude restoration or repair to a usable condition by melting, cutting, tearing, scratching, crushing, breaking, punching, neutralizing, etc. (As an alternate, burial or deep water dumping may be used when coordinated with the DoD Demilitarization Program Office.)
Electro-static Discharge Susceptible:ANo known Electrostatic Discharge (ESD) or Electromagnetic Interference (EMI) sensitivity
Precious Metals Indicator Code:AItem does not contain precious metal
Criticality Code:X The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application.
Automatic Data Processing Equipment:0Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9)
Category Code Description
No Freight Information
