NSN 9540-00-194-9575 AMS101341006, AMS10134-1006 , AMS-QQ-A-200/11
Product Details | STRUCTURAL ANGLE
9540-00-194-9575 A structural shape fabricated from a ferrous or nonferrous material and resembling the letter L in cross-sectional form. The edges may have a bulb, be rounded, and the inside corner may have a fillet.20295200017Structural Shapes95400040Structural Shapes, Nonferrous Base Metal
Part Alternates: AMS101341006, AMS10134-1006 , AMS-QQ-A-200/11, AMSQQA20011, AND101341006, AND10134-1006, AND10134-1006/QQ-A-200/11-T6511, AND101341006QQA20011T6511, ASTM B221, ASTMB221, GS180C37DG, LS1013410065, LS10134-1006-5, QQ-A-200/11, QQA20011, 9540-00-194-9575, 00-194-9575, 9540001949575, 001949575
Metal Bars, Sheets, and Shapes | Structural Shapes, Nonferrous Base Metal
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 95 | 19 DEC 1971 | 00-194-9575 | 37017 ( ANGLE, STRUCTURAL ) |
Drawings & Photos | NSN 9540-00-194-9575
Demand History | NSN 9540-00-194-9575
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| QQA20011 | 2020-01-03 | 1 | US |
| 9540-00-194-9575 | 2019-04-115 | 6 | United States |
| 9540-00-194-9575 | 2018-09-268 | 3 | United States |
| 9540-00-194-9575 | 2018-09-249 | 1 | United States |
| 9540-00-194-9575 | 2018-08-243 | 1 | United States |
| QQA20011 | 2009-10-287 | 14 | FX |
Cross Reference | NSN 9540-00-194-9575
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| AMS-QQ-A-200/11 | 81343 | SOCIETY OF AUTOMOTIVE ENGINEERS INC |
| AMS10134-1006 | 81343 | SOCIETY OF AUTOMOTIVE ENGINEERS INC |
| AND10134-1006 | 01634 | ALUMINUM CO OF AMERICA |
| AND10134-1006 | 99237 | AIRFORCE-NAVY AERONAUTICAL DESIGN STANDARD |
| AND10134-1006/QQ-A-200/11-T6511 | 14153 | DEFENSE LOGISTICS AGENCY DBA DEFENSE SUPPLY CENTER |
| ASTM B221 | 81346 | AMERICAN SOCIETY FOR TESTING AND MATERIALS |
| GS180C37DG | 26512 | NORTHROP GRUMMAN SYSTEMS CORPORATION DIV NORTHROP GRUMMAN AEROSPACE |
| LS10134-1006-5 | 98897 | LOCKHEED MARTIN CORPORATION DBA LOCKHEED MARTIN AERONAUTICS |
| QQ-A-200/11 | 81348 | FEDERAL SPECIFICATIONS PROMULGATED BY GENERAL SERVICES |
