Product Details | SHIPPING SACK

8105-01-027-9124 A container made of three or more walls of various materials or a woven mesh material of natural or synthetic fibers. It may have a square, round, rectangular, satchel, or preformed flat, square bottom. It is used to protect commodities during shipment and storage. For less than three wall construction, see BAG, PAPER.

Part Alternates: AA160, A-A-160, PPPS30, PPP-S-30, PPP-S-30 TY2, PPPS30TY2, 0-SELF SEAL, 0SELFSEAL, 8105-01-027-9124, 01-027-9124, 8105010279124, 010279124

Containers, Packaging, and Packing Supplies | Bags and Sacks

Supply Group (FSG) NSN Assign. NIIN
81 21 SEP 1976 01-027-9124

Drawings & Photos | NSN 8105-01-027-9124


Cross Reference | NSN 8105-01-027-9124

Part Number Cage Code Manufacturer
0-SELF SEAL 51875 SEALED AIR CORP
A-A-160 58536 FEDERAL COMMERCIAL ITEM DESCRIPTION PROMULGATED BY GENERAL SERVICES
PPP-S-30 81348 FEDERAL SPECIFICATIONS PROMULGATED BY GENERAL SERVICES
PPP-S-30 TY2 80244 GENERAL SERVICES ADMINISTRATION FEDERAL SUPPLY SERVICE

Request a Quote

What Our Customers Say

Compare

NSNs for Compare ( up to 4 ): Add 8105-01-027-9124

Technical Data | NSN 8105-01-027-9124

Characteristic Specifications
STYLE DESIGNATOR A4 FLAT
OVERALL HEIGHT 10.000 INCHES NOMINAL
FACE WIDTH 6.000 INCHES NOMINAL
MATERIAL AND LOCATION PAPER, KRAFT SECOND WALL AND PAPER, KRAFT FIRST WALL
NOMINAL BASIS WEIGHT AND LOCATION 60.0 POUNDS PER 500 SHEETS 24 X 36 SECOND WALL AND 40.0 POUNDS PER 500 SHEETS 24 X 36 FIRST WALL
ASSEMBLY METHOD ADHESIVE
OPENING LOCATION ONE END
MANUFACTURERS CODE 58536
NON-DEFINITIVE GOVERNMENT SPEC/STD REFERENCE A-A-160

Restrictions/Controls & Freight Information | NSN 8105-01-027-9124

Category Code Description
Hazardous Material Indicator CodeNThere is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials
Demilitarization Code:ANon-Munitions List Item/ Non-Strategic List Item - Demilitarization not required.
Precious Metals Indicator Code:AItem does not contain precious metal
Criticality Code:X The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application.
Category Code Description
No Freight Information
