NSN 6720-01-067-6063 21007980101, 21007980-101, 01-067-6063
Product Details | PHOTOGRAPHIC CAMERA MIRROR
6720-01-067-6063 00020267100023Cameras, Motion Picture67200022Cameras, Still Picture
Part Alternates: 21007980101, 21007980-101, 6720-01-067-6063, 01-067-6063, 6720010676063, 010676063
Photographic Equipment | Cameras, Still Picture
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 67 | 03 NOV 1978 | 01-067-6063 | 17521 ( MIRROR, PHOTOGRAPHIC CAMERA ) |
Demand History | NSN 6720-01-067-6063
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 6720-01-067-6063 | 2010-05-137 | 1 | Korea |
Cross Reference | NSN 6720-01-067-6063
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 21007980-101 | 81395 | BAE SYSTEMS INFORMATION AND ELECTRONIC SYSTEMS INTEGRATION I |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 6720-01-067-6063
Related Products | NSN 6720-01-067-6063
Technical Data | NSN 6720-01-067-6063
| Characteristic | Specifications |
|---|---|
| MATERIAL | ALUMINUM ALLOY |
| LENGTH | 7.850 INCHES NOMINAL |
| WIDTH | 3.850 INCHES NOMINAL |
| THICKNESS | 0.600 INCHES NOMINAL |
| SPECIAL FEATURES | MIRROR SURFACE COAT HRC SPEC 23683-ES01; INSERTS-SCREW THREAD 3 8-36UNF-2BST1 CSK 120.0 DEG TO 0.19 IN. DIA |
| III END ITEM IDENTIFICATION | AN/AAD-5 INFRARED RECONNAISSANCE SYSTEM |
| MANUFACTURERS CODE | 81395 |
| DESIGN CONTROL REFERENCE | 21007980-101 |
Restrictions/Controls & Freight Information | NSN 6720-01-067-6063
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | D | Munitions List Item or Commerce Control List Item. Demilitarization required. Total destruction of the item and components so as to preclude restoration or repair to a usable condition by melting, cutting, tearing, scratching, crushing, breaking, punching, neutralizing, etc. (As an alternate, burial or deep water dumping may be used when coordinated with the DoD Demilitarization Program Office.) |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 039740 | PHOTOGRAPHERS MATERIALS NOI |
| Less than car load rating | J | 100.2 |
| Less than truck load rating | J | 100.2 |
| Water commodity Code | 756 | unknown |
| Originating Activity Code | SU | Ogden Air Logistics Center Hill AFB, UT 84056-5609 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | P | Photographic supplies and equipment, including training films. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | Z | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
