NSN 6685-01-094-9379 55, 01-094-9379, 010949379
Product Details | OPTICAL PYROMETER
6685-01-094-9379 A pyrometer which measures the quality and intensity of light emitted from a hot body, or glowing material by comparison with a standard source of light and indicated by the position of a pointer relative to a graduated temperature scale.
Part Alternates: 55, 6685-01-094-9379, 01-094-9379, 6685010949379, 010949379
Instruments and Laboratory Equipment | Pressure, Temperature, and Humidity Measuring and Controlling Instruments
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 66 | 20 MAY 1980 | 01-094-9379 | 18521 ( PYROMETER, OPTICAL ) |
Drawings & Photos | NSN 6685-01-094-9379
Demand History | NSN 6685-01-094-9379
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 55 | 2021-12-347 | 2 | Sri Lanka |
| 55 | 2016-11-327 | 1 | US |
| 55 | 2016-11-322 | 1 | US |
| 55 | 2013-10-275 | 2 |
Cross Reference | NSN 6685-01-094-9379
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 55 | 52020 | MIKRON INFRARED INC. |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 6685-01-094-9379
Related Products | NSN 6685-01-094-9379
Technical Data | NSN 6685-01-094-9379
| Characteristic | Specifications |
|---|---|
| MEASUREMENT TYPE | DIGITAL |
| SCALE MEASUREMENT RANGE | 400.000 TO 1000.000 DEG FAHRENHEIT AND 900.000 TO 1800.000 DEG FAHRENHEIT |
| STYLE DESIGNATOR | B6 PORTABLE, HANDHELD |
| OVERALL DEPTH | 2.250 INCHES NOMINAL |
| OVERALL DIAMETER | 8.000 INCHES NOMINAL |
| OVERALL LENGTH | 11.000 INCHES NOMINAL |
| SPECIAL FEATURES | PISTOL SHAPED THERMAL IMAGING THERMOMETER WITH PARALLAX FREE SIGHTING SYSTEM AND GRIP; ACCURACY +/- 2% FULL SCALE; RESOULTION 0.5% FULL SCALE; FIELD OF VIEW 0.750 INCH; SELF CALIBRATING; POWERED BY 2 2.8 VOLT BATTERIES; PORTABLE ITEM; INCLUDES CARRYING CASE, SAFETY STRAP, 2 SPARE BATTERIES AND INSTRUCTIONS |
| III PART NAME ASSIGNED BY CONTROLLING AGENCY | INFRARED THERMOMETER |
Restrictions/Controls & Freight Information | NSN 6685-01-094-9379
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Electro-static Discharge Susceptible: | A | No known Electrostatic Discharge (ESD) or Electromagnetic Interference (EMI) sensitivity |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 058240 | RECORDING DEVICES GAUGES/METERS NOI |
| Less than car load rating | ||
| Less than truck load rating | F | 150.0 |
| Water commodity Code | 652 | unknown |
| Originating Activity Code | SE | San Antonio Air Logistics Center Kelly AFB, TX 78241-5000 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | V | Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above. |
| Air Special Handling | Q | Extremely fragile items including delicate instruments. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | 3 | Electrostatic Sensitive Device (ESD), subject to damage caused by electrostatic discharge. (See DoD 4500.32-R, Volume 1, Appendix A, Section I for additional information on ESD devices). |
Management | NSN 6685-01-094-9379
Air Force| Category | Code | Description |
|---|---|---|
| Fund Code | LP | Items initially authorized for local purchase. |
| Price Validation | N | The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
|
| Materiel Management Aggregation Code | RK | SX:AEROSPACE SUPPORT ACCESSORIES |
| Source of Supply | FHZ | Oklahoma City Air Logistics Center Tinker AFB, OK 73145-5989 |
| Agency | DF | Department of the Air Force |
| Service Organization | L | Lead Service - 22 (Repairable) |
| Reparability | U | AF Equipment Management System (AFEMS) |
| Acquisition Advice Codes | L | LOCAL PURCHASE # (NON-STOCKED ITEMS) Defense Logistics Agency (DLA)/GSA/Service/Agency-managed items authorized for local purchase as normal means of support at base, post, camp or station level. Item not stocked in wholesale distribution system of IMM/Service/Agency ICP. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
