NSN 6685-00-816-4146 M8348B1, M8348-B-1, M8348B1A
Product Details | AIR PRESS GAGE ASSY
6685-00-816-4146 An instrument designed to measure air, gas, fluid, and vapor pressure by means of an internal pressure sensitive element (bellows, bourdon tube, transducer/transmitter and the like) which transmits energy, by direct linkage, to the indicating pointer of a scale or a digital display, calibrated in units of pressure. It may include a temperature equivalent scale. For items that do not have an internal pressure sensitive element see INDICATOR, PRESSURE.205138600004220000042400027Safety and Rescue Equipment66200018Engine Instruments66850073Pressure, Temperature, and Humidity Measuring and Controlling Instruments
Part Alternates: M8348B1, M8348-B-1, M8348B1A, M8348-B1A, MILDTL8348J, MIL-DTL-8348J, MILG8348H, MIL-G-8348H, 6685-00-816-4146, 00-816-4146, 6685008164146, 008164146
Instruments and Laboratory Equipment | Pressure, Temperature, and Humidity Measuring and Controlling Instruments
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 66 | 01 JAN 1962 | 00-816-4146 | 07428 ( GAGE, PRESSURE, DIAL INDICATING ) |
