Product Details | HEATING ELEMENT THERMOCOUPLE

6685-00-773-2763 A thermocouple which includes a resistance element designed to transfer heat of the element to its thermojunction.

Part Alternates: 13132RPC1, 13133RPC1, 98486APC1, 98561A1CPC1, 98561APCALL, 6685-00-773-2763, 00-773-2763, 6685007732763, 007732763

Instruments and Laboratory Equipment | Pressure, Temperature, and Humidity Measuring and Controlling Instruments

Supply Group (FSG) NSN Assign. NIIN
66 01 JAN 1963 00-773-2763

Cross Reference | NSN 6685-00-773-2763

Part Number Cage Code Manufacturer
13132RPC1 73475 ROBERTSHAW CONTROLS COMPANY DBA ROBERTSHAW INDUSTRIAL PRODUCTS
13133RPC1 73475 ROBERTSHAW CONTROLS COMPANY DBA ROBERTSHAW INDUSTRIAL PRODUCTS
98486APC1 73475 ROBERTSHAW CONTROLS COMPANY DBA ROBERTSHAW INDUSTRIAL PRODUCTS
98561A1CPC1 73475 ROBERTSHAW CONTROLS COMPANY DBA ROBERTSHAW INDUSTRIAL PRODUCTS
98561APCALL 73475 ROBERTSHAW CONTROLS COMPANY DBA ROBERTSHAW INDUSTRIAL PRODUCTS

Request a Quote

What Our Customers Say

Compare

NSNs for Compare ( up to 4 ): Add 6685-00-773-2763

Technical Data | NSN 6685-00-773-2763

Characteristic Specifications
MOUNTING LOCATION INSIDE METER CASE
CASE TYPE ROUND
MANUFACTURERS CODE 73475
DESIGN CONTROL REFERENCE 98561A1CPC1

Restrictions/Controls & Freight Information | NSN 6685-00-773-2763

Category Code Description
Shelf-Life Code:0Nondeteriorative
Hazardous Material Indicator CodePThere is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product
Demilitarization Code:ANon-Munitions List Item/ Non-Strategic List Item - Demilitarization not required.
Controlled Inventory Item Code:UUNCLASSIFIED
Precious Metals Indicator Code:AItem does not contain precious metal
Criticality Code:X The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application.
Automatic Data Processing Equipment:0Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9)
Category Code Description
NMF Description 061700 ELEC APPLIANCES/INSTRUMENTS NOI
Less than car load rating
Less than truck load rating W Rating Variable
Water commodity Code 658 unknown
Originating Activity Code XX
Air Dimension Code A Shipment is not a consolidation and does not exceed 72 inches in any dimension.
Air Commodity V Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above.
Air Special Handling Q Extremely fragile items including delicate instruments.
Special Handling Code 9 unknonwn
HAZMAT
Type of Cargo Z No special type of cargo code applicable

Management | NSN 6685-00-773-2763

Category Code Description
Cognizance Codes9BNavy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Source of SupplySMSDefense Logistics Agency
Enterprise Business Systems
AgencyDNDepartment of the Navy
Service OrganizationNU.S. Navy
Acquisition Advice CodesZINSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures.
Controlled Item CodeUUNCLASSIFIED
Shelf Life Code0Nondeteriorative
Purchasing QTY
UOM
1
EA : Each
