NSN 6685-00-723-1738 2865, 4, 00-723-1738
Product Details | INDICATING PYROMETER
6685-00-723-1738 A pyrometer which utilizes the effect of temperature variation to change the characteristics of an electrical constant and this difference of electrical potential is shown by the position of a pointer relative to a graduated scale.
Part Alternates: 2865, 4, 6685-00-723-1738, 00-723-1738, 6685007231738, 007231738
Instruments and Laboratory Equipment | Pressure, Temperature, and Humidity Measuring and Controlling Instruments
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 66 | 01 JAN 1963 | 00-723-1738 | 07343 ( PYROMETER, INDICATING ) |
Demand History | NSN 6685-00-723-1738
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 4 | 2022-03-75 | 0 | |
| 4 | 2022-03-70 | 0 | |
| 4 | 2018-03-74 | 7 | |
| 4 | 2016-04-110 | 40 | US |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 6685-00-723-1738
Related Products | NSN 6685-00-723-1738
Technical Data | NSN 6685-00-723-1738
| Characteristic | Specifications |
|---|---|
| MEASUREMENT TYPE | MILLIVOLT CIRCUIT |
| SCALE TYPE | ECCENTRIC |
| MATERIAL | WOOD CARRYING CASE |
| OVERALL HEIGHT | 4.437 INCHES NOMINAL |
| OVERALL LENGTH | 8.625 INCHES NOMINAL |
| OVERALL WIDTH | 8.625 INCHES NOMINAL |
| SCALE LENGTH | 5.750 INCHES NOMINAL |
| POINTER/PEN TYPE AND QUANTITY | 1 INDICATING SINGLE |
| CASE TYPE | HINGED LID CARRYING CASE W/HANDLE |
| REFERENCE NUMBER DIFFERENTIATING CHARACTERISTICS | AS DIFFERENTIATED BY SCALE RANGE,SCALE ACCURACY AND SCALE CALIBRATION |
| III SCALE ACCURACY RATING | PORM 3 DEG F ACCURACY RATING |
| III SCALE CALIBRATION | CALIBRATED TO IRON CONSTANTAN THERMOCOUPLE |
| III SCALE SMALLEST INCREMENT | 5.0 DEG FAHRENHEIT |
| MANUFACTURERS CODE | 05624 |
| DESIGN CONTROL REFERENCE | 2865 |
Restrictions/Controls & Freight Information | NSN 6685-00-723-1738
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 058240 | RECORDING DEVICES GAUGES/METERS NOI |
| Less than car load rating | J | 100.2 |
| Less than truck load rating | F | 150.0 |
| Water commodity Code | 72E | unknown |
| Originating Activity Code | XX | |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | R | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 6685-00-723-1738
Air Force| Category | Code | Description |
|---|---|---|
| Price Validation | N | The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
|
| Materiel Management Aggregation Code | RN | TG:GROUND SUPPORT EQUIPMENT (FSC RESIDUAL MMAC) |
| Budget Code | Y | variousO & M:AF centrally procured equipment items. They are separate, primary end items (other than the weapon system itself) needed by a user to perform an assigned mission. They are nonexpendable items (ERRCD NF or ND) which are not consumed in use, and they do not lose their original identity during periods of use by incorporation into, or attachment to another assembly. |
| Source of Supply | JCD | |
| Agency | DF | Department of the Air Force |
| Service Organization | L | Lead Service - 22 (Repairable) |
| Reparability | S | AF Equipment Management System (AFEMS) |
| Acquisition Advice Codes | Y | TERMINAL ITEM #(NON-STOCKED ITEMS) Future procurement is not authorized. No wholesale stock is available for issue. 1. Requisitions will not be processed to the wholesale manager. 2. Internal Service/agency requisitioning may be continued in accordance with the Service/agency requisitioning policies. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
