NSN 6685-00-566-1995 2010MP, 00-566-1995, 005661995
Product Details | DIAL INDICATING DIFFERENTIAL GAGE
6685-00-566-1995 An instrument designed to measure air, gas, fluid, and vapor differential by means of a pressure sensitive element(s) which transmits energy, by direct linkage, to the indicating pointer of a scale calibrated to units of pressure. The scale may indicate in units of pressure, quantity, or flow.
Part Alternates: 2010MP, 6685-00-566-1995, 00-566-1995, 6685005661995, 005661995
Instruments and Laboratory Equipment | Pressure, Temperature, and Humidity Measuring and Controlling Instruments
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 66 | 24 NOV 1974 | 00-566-1995 | 62209 ( GAGE, DIFFERENTIAL, DIAL INDICATING ) |
Demand History | NSN 6685-00-566-1995
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 2010-MP | 2019-08-235 | 10 | DIBBS |
| 6685-00-566-1995 | 2016-06-153 | 20 | DIBBS |
| 6685-00-566-1995 | 2016-03-63 | 20 | DIBBS |
| 6685-00-566-1995 | 2009-12-337 | 7 | DIBBS |
Cross Reference | NSN 6685-00-566-1995
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 2010MP | 85274 | DWYER INSTRUMENTS INC DIV DWYER INSTRUMENTS, INC |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 6685-00-566-1995
Related Products | NSN 6685-00-566-1995
Technical Data | NSN 6685-00-566-1995
| Characteristic | Specifications |
|---|---|
| ACTUATION TYPE | DIAPHRAGM |
| ACTUATING ELEMENT MATERIAL | SILICONE RUBBER |
| SCALE TYPE | SINGLE |
| SCALE NAME | DIFFERENTIAL PRESSURE |
| SCALE RANGE | 0.0 TO 10.0 INCHES OF WATER PRESSURE |
| SCALE ACCURACY | PORM 2 PCT FULL RANGE |
| GRADUATION UNIT | 2.0 INCHES |
| SCALE SMALLEST INCREMENT | 0.2 INCHES |
| SCALE INSCRIPTION/BACKGROUND COLOR | BLACK MARKINGS ON WHITE BACKGROUND |
| DIAL SIZE | 4 IN. DIA |
| POINTER TYPE | INDICATING |
| ADJUSTABILITY | ADJUSTABLE |
| POINTER COLOR | ALUMINUM |
| CASE MATERIAL | ALUMINUM, DIE CAST |
| CASE SURFACE TREATMENT | BAKED DARK GRAY HAMMERIOID |
| OVERALL DIAMETER | 4.750 INCHES NOMINAL |
| OVERALL DEPTH | 2.188 INCHES NOMINAL |
| BEZEL TYPE | THREAD |
| MATERIAL | ALUMINUM, DIE CAST |
| SURFACE TREATMENT | BAKED DARK GRAY HAMMERIOID |
| PROTECTIVE CRYSTAL MATERIAL | PLASTIC |
| CONNECTION QUANTITY | 4 |
| CONNECTION TYPE | INTERNAL |
| CONNECTION LOCATION | BACK AND SIDE |
| CONNECTION SIZE | 0.125 IN. NPT DIA |
| MOUNTING METHOD | FLUSH OR SURFACE |
| BOLT CIRCLE DIAMETER | 4.125 INCHES NOMINAL |
| MOUNTING HOLE QUANTITY | 3 |
| MOUNTING HOLE DIAMETER | 0.250 INCHES NOMINAL |
| CONNECTOR TYPE VENT | NOT PROVIDED |
| SPECIAL FEATURES | RED TIP POINTER |
| MANUFACTURERS CODE | 85274 |
| DESIGN CONTROL REFERENCE | 2010MP |
Restrictions/Controls & Freight Information | NSN 6685-00-566-1995
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 121570 | GAGES AIR LIQUID LEVEL PRESSURE |
| Less than car load rating | ||
| Less than truck load rating | J | 100.2 |
| Water commodity Code | 651 | unknown |
| Originating Activity Code | CX | Defense Supply Center Richmond Richmond, VA 23297-5000 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | B | Construction materials: Includes paint and related materials, prefabricated building, wood products, metal and composition materials and their products, commercial hardware and miscellaneous items, cement, asphalt, building maintenance materials. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 6685-00-566-1995
Air Force
Navy| Category | Code | Description |
|---|---|---|
| Budget Code | 9 | General Support DIV57X4921.070:Air Force decentrally managed expense items (ERRC XB3, XF-3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors. |
| Price Validation | N | The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
|
| Fund Code | SF | Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point. |
| Materiel Management Aggregation Code | SX | SX:AF SICA RESIDUAL MMAC-OC-ALC |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DF | Department of the Air Force |
| Service Organization | F | U.S. Air Force |
| Reparability | N | Stock Fund (except Munitions) |
| Acquisition Advice Codes | J | NOT STOCKED, CENTRALLY PROCURED # (NON-STOCKED ITEMS) IMM/Service centrally managed but not stocked item. Procurement will be initiated only after receipt of a requisition. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | J | NOT STOCKED, CENTRALLY PROCURED # (NON-STOCKED ITEMS) IMM/Service centrally managed but not stocked item. Procurement will be initiated only after receipt of a requisition. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
