Product Details | ELECTRICAL RESISTANCE TEMPERATURE TRANSMITTER

6685-00-373-9004 A device having a temperature sensing element whose electrical resistance varies with a change in temperature. It is designed to transmit information relative to temperature to an INDICATOR, TEMPERATURE, ELECTRICAL RESISTANCE. It may be a component part of a THERMOMETER, INDICATING, RESISTANCE; THERMOMETER, RECORDING, RESISTANCE. Excludes THERMOCOUPLE (as modified).

Part Alternates: MS280341, MS28034-1, AN55251R, AN5525-1R, MILDTL7990, MIL-DTL-7990 , MILT7990, MIL-T-7990, 73650390001, 736-50390001, 10200000, 102-00000, 23200002, 232-0000-2, 453 742, 453742, 506431, 50643-1, 56B3A, 6685-00-373-9004, 00-373-9004, 6685003739004, 003739004
