Product Details | SELF-INDICATING THERMOMETER

6685-00-070-9755 An item that has confined liquid whose physical property(ies) changes with variation in temperature and indicates the temperature to a division or number on a graduated scale(s). May include flexible tubing (capillary) for indoor/outdoor applications. Excludes: THERMOMETER, CLINICAL, HUMAN.20365150057Medical and Surgical Instruments, Equipment, and Supplies66600040Meteorological Instruments and Apparatus66850073Pressure, Temperature, and Humidity Measuring and Controlling Instruments

Part Alternates: 6311G, 6685-00-070-9755, 00-070-9755, 6685000709755, 000709755

Instruments and Laboratory Equipment | Pressure, Temperature, and Humidity Measuring and Controlling Instruments

Supply Group (FSG) NSN Assign. NIIN
66 20 JUL 1967 00-070-9755

Drawings & Photos | NSN 6685-00-070-9755


Cross Reference | NSN 6685-00-070-9755

Part Number Cage Code Manufacturer
6311G 21518 TYCOS INSTRUMENTS INC A WELCH ALLYN CO

Request a Quote

What Our Customers Say

Compare

NSNs for Compare ( up to 4 ): Add 6685-00-070-9755

Technical Data | NSN 6685-00-070-9755

Characteristic Specifications
SCALE TYPE ETCHED STEM
SCALE MEASUREMENT RANGE -30.000 TO 120.000 DEG FAHRENHEIT
MATERIAL GLASS OVERALL
STYLE DESIGNATOR A14 IMMERSION RING TOP
OVERALL DIAMETER ANY ACCEPTABLE
OVERALL LENGTH 12.000 INCHES NOMINAL
SCALE LENGTH ANY ACCEPTABLE
ACTUATING MEDIUM MERCURY
DESIGN TYPE FLUCTUATING
SECURING DEVICE TYPE CLIP
III SCALE INSCRIPTION/BACKGROUND COLOR BLACK MARKING ON GOLD BACKGROUND
III SCALE SMALLEST INCREMENT 1.0 DEG FAHRENHEIT

Restrictions/Controls & Freight Information | NSN 6685-00-070-9755

Category Code Description
Shelf-Life Code:0Nondeteriorative
Hazardous Material Indicator CodePThere is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product
Demilitarization Code:ANon-Munitions List Item/ Non-Strategic List Item - Demilitarization not required.
Controlled Inventory Item Code:UUNCLASSIFIED
Precious Metals Indicator Code:AItem does not contain precious metal
Criticality Code:X The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application.
Category Code Description
NMF Description 053025 COOLERS,ICEBOXES,REFRIGERATORS
Less than car load rating
Less than truck load rating W Rating Variable
Water commodity Code 651 unknown
Originating Activity Code 37 Department of Interior
Washington, DC 20006
Air Dimension Code A Shipment is not a consolidation and does not exceed 72 inches in any dimension.
Air Commodity V Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above.
Air Special Handling Z No special handling required.
Special Handling Code 9 unknonwn
HAZMAT
Type of Cargo Z No special type of cargo code applicable

Management | NSN 6685-00-070-9755

Category Code Description
Budget Code9 General Support DIV57X4921.070:Air Force decentrally managed expense items (ERRC XB3, XF-3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors.
Price ValidationN The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
  • The price has not been analyzed or reviewed for accuracy.
  • ZOP or Standard price challenges are permissible, but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of ?L? or?F?,the case must be evaluated locally where purchased or fabricated.
Fund CodeSFStock fund applicable to items managed for the Air Force by the respective Inventory Control Point.
Materiel Management Aggregation CodeSXSX:AF SICA RESIDUAL MMAC-OC-ALC
Source of SupplySMSDefense Logistics Agency
Enterprise Business Systems
AgencyDFDepartment of the Air Force
Service OrganizationFU.S. Air Force
ReparabilityNStock Fund (except Munitions)
Acquisition Advice CodesJNOT STOCKED, CENTRALLY PROCURED # (NON-STOCKED ITEMS) IMM/Service centrally managed but not stocked item. Procurement will be initiated only after receipt of a requisition.
Controlled Item CodeUUNCLASSIFIED
Shelf Life Code0Nondeteriorative
Purchasing QTY
UOM
1
EA : Each
