Product Details | LIQUID QUANTITY INDICATOR

6680-00-936-3458 An indicator which indicates the amount of liquid contained in a tank, vessel, chamber, and like items.

Part Alternates: SP25211, SP2521-1, SP25211CES, SP-2521-1-CES, 6680-00-936-3458, 00-936-3458, 6680009363458, 009363458

Instruments and Laboratory Equipment | Liquid and Gas Flow, Liquid Level, and Mechanical Motion Measuring Instruments

Supply Group (FSG) NSN Assign. NIIN
66 03 MAR 1967 00-936-3458

Cross Reference | NSN 6680-00-936-3458

Part Number Cage Code Manufacturer
SP-2521-1-CES 21908 NCR CORP POWER SYSTEMS DIV
SP-2521-1-CES 86887 SIGMA TEK, INC.
SP2521-1 21908 NCR CORP POWER SYSTEMS DIV

Request a Quote

What Our Customers Say

Compare

NSNs for Compare ( up to 4 ): Add 6680-00-936-3458

Technical Data | NSN 6680-00-936-3458

Characteristic Specifications
PRESENTATION TYPE DIAL
CURRENT TYPE DC
DC VOLTAGE RATING 23.0 VOLTS MINIMUM AND 31.0 VOLTS MAXIMUM
LENGTH 4.500 INCHES NOMINAL
DIAMETER 3.130 INCHES NOMINAL
SPECIAL FEATURES MOUNTING PER MS33638; WEIGHT 1 LBOPERATING TEMP -30 TO 50 DEG C
III END ITEM IDENTIFICATION 02-A ACFT
III PART NAME ASSIGNED BY CONTROLLING AGENCY FUEL QUNATITY INDICATOR

Restrictions/Controls & Freight Information | NSN 6680-00-936-3458

Category Code Description
Hazardous Material Indicator CodeNThere is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials
Demilitarization Code:ANon-Munitions List Item/ Non-Strategic List Item - Demilitarization not required.
Electro-static Discharge Susceptible:ANo known Electrostatic Discharge (ESD) or Electromagnetic Interference (EMI) sensitivity
Precious Metals Indicator Code:AItem does not contain precious metal
Criticality Code:X The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application.
Automatic Data Processing Equipment:0Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9)
Category Code Description
NMF Description 136740 METERS ELEC/PARTS SUB1
Less than car load rating
Less than truck load rating J 100.2
Water commodity Code 657 unknown
Originating Activity Code SX Oklahoma City Air Logistics Center
Tinker AFB, OK 73145-3043
Air Dimension Code A Shipment is not a consolidation and does not exceed 72 inches in any dimension.
Air Commodity
Air Special Handling Q Extremely fragile items including delicate instruments.
Special Handling Code Q unknonwn
HAZMAT
Type of Cargo Z No special type of cargo code applicable
