NSN 6680-00-063-3561 BM76284, 153786, 00-063-3561
Product Details | LIQUID LEVEL GAGE ROD-CAP
6680-00-063-3561 A thin metal strip, of various cross-sectional shapes, having graduations on one end and must have a cap on the opposite end, and may have a handle. It is designed to be inserted into an engine, pump, or compressor crankcase, transmission, gearcase, fuel tank, or the like, to determine the level of the liquid. For items with an integral breather, see GAGE ROD-BREATHER, LIQUID LEVEL and items without a cap or breather, see GAGE ROD, LIQUID LEVEL. For items designed to measure the liquid level of bulk petroleum tanks, see GAGE STICK, PETROLEUM.
Part Alternates: BM76284, 153786, 6680-00-063-3561, 00-063-3561, 6680000633561, 000633561
Instruments and Laboratory Equipment | Liquid and Gas Flow, Liquid Level, and Mechanical Motion Measuring Instruments
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 66 | 01 JAN 1961 | 00-063-3561 | 22252 ( GAGE ROD-CAP, LIQUID LEVEL ) |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 6680-00-063-3561
Technical Data | NSN 6680-00-063-3561
| Characteristic | Specifications |
|---|---|
| MATERIAL | STEEL |
| SURFACE TREATMENT | CADMIUM PLATED |
| OVERALL LENGTH | 26.391 INCHES NOMINAL |
| ROD LENGTH FROM END TO CAP | 23.125 INCHES |
| ROD MEASURING PORTION WIDTH | 0.250 INCHES NOMINAL |
| ROD MEASURING PORTION THICKNESS | 0.125 INCHES NOMINAL |
| HANDLE | FURNISHED |
| CAP TYPE | THREADED |
| THREAD SIZE | 1-8 |
| SCREW THREAD SERIES DESIGNATOR | UNC |
| DISTANCE FROM ROD END TO SCALE GRADUATION | 0.500 INCHES NOMINAL |
| SCALE INSCRIPTION | L AND H |
| MANUFACTURERS CODE | 15434 |
| DESIGN CONTROL REFERENCE | 153786 |
Restrictions/Controls & Freight Information | NSN 6680-00-063-3561
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 121570 | GAGES AIR LIQUID LEVEL PRESSURE |
| Less than car load rating | ||
| Less than truck load rating | J | 100.2 |
| Water commodity Code | 593 | unknown |
| Originating Activity Code | XX | |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | V | Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 6680-00-063-3561
Army| Category | Code | Description |
|---|---|---|
| Materiel Category and Inventory Manager | J | Ground Forces Support Materiel (DLA/GSA Items) |
| Appropriation and Budget Activity | 2 | Stock Fund Secondary Items |
| Management Inventory Segment | 2 | NONREPARABLE ITEMS (Exclusive of Insurance and Provisioning Items). This code will be used to identify items which are not reparable. |
| Specific Group/Generic Code | 0 | Medical Materiel |
| Weapons Systems/End Item or Homogeneous Group | 00 | DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item |
| Accounting Requirements Code | X | Expendable item. An item of Army property coded with an ARC of ?X? in the AMDF. Expendable items require no formal accountability after issue from a stock record account. Commercial and fabricated items similar to items coded ?X? in the AMDF are considered expendable items. |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DA | Department of the Army |
| Service Organization | A | U.S. Army |
| Reparability | Z | This is a nonreparable item. If condemned or economically unserviceable, then dispose at the level authorized replace the item. |
| Acquisition Advice Codes | L | LOCAL PURCHASE # (NON-STOCKED ITEMS) Defense Logistics Agency (DLA)/GSA/Service/Agency-managed items authorized for local purchase as normal means of support at base, post, camp or station level. Item not stocked in wholesale distribution system of IMM/Service/Agency ICP. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
