NSN 6675-01-559-7329 208355, 20-8355, 01-559-7329
Product Details | SURVEYING THEODOLITE
6675-01-559-7329 A precision telescopic instrument used in topographic and geodetic surveying or precise alignment operations. Generally, the optical systems for reading the horizontal and vertical circles are fully inclosed. The reading of the circles is made through optical micrometers. Some optical systems are so designed that readings of diametrically opposite points of the circles are mechanically averaged. The instruments are leveled by three leveling screws. Internal illumination may be provided for reading the circles and viewing the reticle crosslines. Excludes TRANSIT and TRANSIT, POCKET.
Part Alternates: 208355, 20-8355, 6675-01-559-7329, 01-559-7329, 6675015597329, 015597329
Instruments and Laboratory Equipment | Drafting, Surveying, and Mapping Instruments
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 66 | 03 JAN 2008 | 01-559-7329 | 18488 ( THEODOLITE, SURVEYING ) |
Demand History | NSN 6675-01-559-7329
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 6675-01-559-7329 | 2023-05-135 | 2 | United States |
| 6675-01-559-7329 | 2018-12-339 | 1 | US |
Cross Reference | NSN 6675-01-559-7329
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 20-8355 | 63848 | WARREN INDUSTRIES, INCORPORATED DBA WARREN KNIGHT INSTRUMENT CO |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 6675-01-559-7329
Technical Data | NSN 6675-01-559-7329
| Characteristic | Specifications |
|---|---|
| SPECIAL FEATURES | PRESCISON MEASURING SYSTEM USED BY THE FAA FOR CALIBRATION OF INSTRUMENT LANDING SYSTEM (ILS), MLS, VOR, TACAN, VORTAC, AND OTHER NAVIGATIONAL AIDS. IN ILS CALIBRATION, AN OPERATOR TRACKS THE FLIGHT CHECK AIRCRAFT AND ADJUSTS THE THEODOLITE SO THAT THE IMAGE REMAINS IN THE CROSSHAIRS. |
| III PART NAME ASSIGNED BY CONTROLLING AGENCY | TELEMETERING THEODOLITE |
Restrictions/Controls & Freight Information | NSN 6675-01-559-7329
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | Q | Strategic List Item (SLI). Demilitarization not required. SLI are non-MLI(Munitions List Items) controlled by the U.S. Dept. of Commerce through the Export Administration Regulations (EAR) and indicated on the Commerce Control List (CCL). Each CCL entry is preceded by a four-digit Export Control Commerce Control List Item (CCLI) – MUT to the point of scrap required outside the United States. Inside the United States, MUT is required when the DEMIL integrity code (IC) is “3” and MUT is not required when the DEMIL IC is “6.” |
| Electro-static Discharge Susceptible: | A | No known Electrostatic Discharge (ESD) or Electromagnetic Interference (EMI) sensitivity |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| No Freight Information | ||
