NSN 6645-00-663-4669 12C1063, 12C106-3, 00-663-4669
Product Details | INTERVAL TIMER
6645-00-663-4669 An instrument for signalling the expiration of a predetermined time. It may also have an automatic switch for control of electrical circuits See also TIMER, STOP.20366450000692000006930000000
Part Alternates: 12C1063, 12C106-3, 6645-00-663-4669, 00-663-4669, 6645006634669, 006634669
Instruments and Laboratory Equipment | Time Measuring Instruments
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 66 | 01 JAN 1963 | 00-663-4669 | 04842 ( TIMER, INTERVAL ) |
Cross Reference | NSN 6645-00-663-4669
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 12C106-3 | 99319 | INTERMOUNTAIN THEATRE SUPPLY CO |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 6645-00-663-4669
Related Products | NSN 6645-00-663-4669
Technical Data | NSN 6645-00-663-4669
| Characteristic | Specifications |
|---|---|
| TIMER TYPE | ELECTRICAL |
| OPERATION METHOD | SYNCHRONOUS MOTOR |
| CURRENT TYPE | AC |
| VOLTAGE IN VOLTS | 115.0 |
| FREQUENCY IN HERTZ | 60.0 |
| AUTOMATIC ELECTRIC CIRCUIT CONTROL SWITCH | INCLUDED |
| CONTROL SWITCH VOLTAGE IN VOLTS | 115.0 |
| CURRENT RATING | 3.000 AMPERES |
| SWITCH TYPE | AUTOMATIC OFF TYPE |
| CONTROL SWITCH OUTLET TAP LOCATION | ON CASE |
| INTERVAL EXPIRATION SIGNALLING DEVICE | NOT INCLUDED |
| DIAL BACKGROUND COLOR | BLACK |
| TIME INDICATOR TOTAL CAPACITY | 60 SEC |
| DIAL MINIMUM GRADUATION | 1 SEC |
| HAND DESIGNATION AND QUANTITY | 1 SWEEP SECOND HAND |
| HAND COLOR | ANY ACCEPTABLE |
| LUMINOUS HAND | NOT INCLUDED |
| ILLUMINATED FEATURE | NOT INCLUDED |
| CASE MATERIAL | METAL |
| MOUNTING METHOD | TABLE |
| INDEPENDENTLY OPERATED CLOCK | NOT INCLUDED |
| OVERALL HEIGHT | 4.000 INCHES NOMINAL |
| OVERALL WIDTH | 4.060 INCHES NOMINAL |
| OVERALL DEPTH | 2.620 INCHES NOMINAL |
| III END ITEM IDENTIFICATION | TYPE NO.PH-649/U |
| MANUFACTURERS CODE | 99319 |
| DESIGN CONTROL REFERENCE | 12C106-3 |
Restrictions/Controls & Freight Information | NSN 6645-00-663-4669
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 061700 | ELEC APPLIANCES/INSTRUMENTS NOI |
| Less than car load rating | M | 85 |
| Less than truck load rating | J | 100.2 |
| Water commodity Code | 72D | unknown |
| Originating Activity Code | XX | |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | V | Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 6645-00-663-4669
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 1H | Consumable material assigned to NAVICP MECH for inventory management Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | N35 | Naval Inventory Control Point Mechanicsburg, PA 17055-0788 |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Reparability | D | Field Level Reparables |
| Acquisition Advice Codes | C | SERVICE/AGENCY-MANAGED (Service/Agency use only.) # Issue, transfer, or shipment is not subject to specialized controls other than those imposed by individual Services supply policy. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
