NSN 6635-00-578-5203 AFK2D, ID712G, MILI26343
Product Details | MOISTURE CONTENT DETECTOR
6635-00-578-5203 An electrical or battery operated device for the measurement of moisture and its percentage in wood, plaster, brick, concrete, paper, grain, and the like, without marring the sample. Item may be portable or transportable and uses various types or electrodes, or radio-active source to take readings.
Part Alternates: AFK2D, ID712G, MILI26343, K2D, 6635-00-578-5203, 00-578-5203, 6635005785203, 005785203
Instruments and Laboratory Equipment | Physical Properties Testing and Inspection
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 66 | 01 APR 1970 | 00-578-5203 | 33656 ( DETECTOR, MOISTURE CONTENT ) |
Cross Reference | NSN 6635-00-578-5203
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 6635-00-578-5203
Technical Data | NSN 6635-00-578-5203
| Characteristic | Specifications |
|---|---|
| TIP TERMINATION TYPE | PROBE |
| TIP REPLACEABILITY FEATURE | INCLUDED |
| CONDUCTOR ATTACHMENT METHOD | PROBE CONNECTION 1/4 INCH DIAMETER |
| FURNISHED ITEMS AND QUANTITY | PROBE UNIT 1; CARRYING CASE 1 |
| SPECIAL FEATURES | DIRECT READING COLORED COMPARATOR SCALE FOR INSTANTANEOUS INDICATION OF MOISTURE; INCLUDES CARRYING CASE AND CHARGING CORD; ITEM CONSISTS OF 2 BASIC COMPONENTS: ELECTRODE GUN AND METERING UNIT CONNECTED BY 3 FT CABLE; SCALE CALIBRATED SPECIFICALLY FOR RADOMES; INCLUDES LOW BATTERY CHARGE INDICATION |
| III SUPPLEMENTARY FEATURES | INDICATOR RADOME MOISTURE METER |
| III FUNCTIONAL DESCRIPTION | INDICATES THE MOISTURE POCKETS IN AIRCRAFT RADOMES BY MEASURING THE RADIO FREQUENCY DIELECTRIC POWER LOSS OF MATERIAL IN CONTACT WITH THE ELECTRODE SENSOR |
| MANUFACTURERS CODE | 81349 |
| NON-DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | MILI26343 |
Restrictions/Controls & Freight Information | NSN 6635-00-578-5203
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Electro-static Discharge Susceptible: | A | No known Electrostatic Discharge (ESD) or Electromagnetic Interference (EMI) sensitivity |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 058280 | SCIENTIFIC INSTRUMENTS NOI |
| Less than car load rating | U | 50 |
| Less than truck load rating | D | 200.0 |
| Water commodity Code | 72E | unknown |
| Originating Activity Code | SE | San Antonio Air Logistics Center Kelly AFB, TX 78241-5000 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
