Product Details | SIGNAL GENERATOR
6625-01-583-6234 An instrument which produces a continuous audio and/or radio frequency voltage, and which is designed for test purposes only. It may provide an output at one or more fixed frequencies or be continuously variable over one or more bands. The fixed frequency type is distinguished from CALIBRATOR, FREQUENCY in that it is a voltage source and is not primarily intended for checking frequencies from other sources. Excludes GENERATOR, INTERFERENCE.
Part Alternates: E8257D520UNTUNU1E11ED1EM, E8257D-520-UNT-UNU-1E1-1ED-1EM--, 6625-01-583-6234, 01-583-6234, 6625015836234, 015836234
Instruments and Laboratory Equipment | Electrical and Electronic Properties Measuring and Testing Instruments
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 66 | 30 MAR 2010 | 01-583-6234 | 03901 ( GENERATOR, SIGNAL ) |
Cross Reference | NSN 6625-01-583-6234
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| E8257D-520-UNT-UNU-1E1-1ED-1EM-- | 1LQK8 | KEYSIGHT TECHNOLOGIES, INC. |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 6625-01-583-6234
Related Products | NSN 6625-01-583-6234
Technical Data | NSN 6625-01-583-6234
| Characteristic | Specifications |
|---|---|
| FUNCTIONAL DESCRIPTION | FULLY SYNTHESIZED SIGNAL GENERATOR WITH HIGH OUTPUT POWER AND LOW PHASE NOISE |
| REFERENCE NUMBER DIFFERENTIATING CHARACTERISTICS | EXTRA LONG REFERENCE NUMBER |
| EXTRA LONG REFERENCE NUMBER | E8257D-520-UNT-UNU-1E1-1ED-1EM-1CP |
| PART NAME ASSIGNED BY CONTROLLING AGENCY | MICROWAVE ANALOG SIGNAL GENERATOR |
| SPECIAL FEATURES | OPTIONS: 520 FREQUENCY RANGE FROM 250 KHZ TO 20 GHZ; UNT ADDS INTERNALLY OR EXTERNALLY DRIVEN AM, FM AND OM SIGNALS AND AN INTERNAL LOW FREQUENCY MMODULATION GENERATOR (LF); UNU ADDS STANDARD PULSE MODULATION; 1E1 ADDS A STEP ATTENUATOR TO PROVIDE CALIBRATED MINIMUM OUTPUT POWER LEVELS OF -135 DBM (UP TO 40GHZ) AND 110 DBM (UP TO 70 GHZ) WHILE MAINTAINING SUPERIOR LEVEL ACCURACY; 1ED TYPE-N (F) RF OUTPUT CONNECTOR; 1EM MOVES ALL FRONT PANEL CONNECTORS TO THE REAR PANEL; 1CP RACKMOUNT KIT WITH FRONT HANDLES |
