NSN 6625-01-533-1471 M1071AS5, M1071-AS5, 01-533-1471
Product Details | FREQUENCY MULTIPLIER
6625-01-533-1471 An electronic device for delivering an output wave whose frequency is a multiple of the input frequency. It may also provide incidental signal amplification.2071677000058200061Radio and Television Communication Equipment, Except Airborne58250043Radio Navigation Equipment, Except Airborne58260036Radio Navigation Equipment, Airborne58650091Electronic Countermeasures, Counter-Countermeasures and Quick Reaction Capability Equipment58950037Miscellaneous Communication Equipment66250070Electrical and Electronic Properties Measuring and Testing Instruments
Part Alternates: M1071AS5, M1071-AS5, 6625-01-533-1471, 01-533-1471, 6625015331471, 015331471
Instruments and Laboratory Equipment | Electrical and Electronic Properties Measuring and Testing Instruments
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 66 | 01 SEP 2005 | 01-533-1471 | 00333 ( FREQUENCY MULTIPLIER ) |
Cross Reference | NSN 6625-01-533-1471
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| M1071-AS5 | 58792 | TECHTROL CYCLONETICS, INC. |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 6625-01-533-1471
Technical Data | NSN 6625-01-533-1471
| Characteristic | Specifications |
|---|---|
| SPECIAL FEATURES | TO INCLUDE CASE, COVER PLATE, 5 FILTER ROD, 1 IDLER ROD, 1 DIODE MOUNT, 1 STEP RECOVERY DIODE CR1, 17 SCREW NUMBER 1-64 UNC-2B FLAT HEAD X 3/16 IN LONG, 4 SCREW NUMBER 2-56 UNC-2B PAN HEAD X 3/16 IN LONG, 2 SCREW NUMBER 2-56 UNC-2B PAN HEAD X 5/16 IN LONG, 3 SCREW NUMBER 2-56 UNC-2B PAN HEAD X 3/8 IN LONG, 9 NUMBER 2 SPLIT RING LOCK WASHER |
| III END ITEM IDENTIFICATION | M1071-AS6, SYSTEM PLATE ASSEMBLY |
| III PART NAME ASSIGNED BY CONTROLLING AGENCY | AS5 UNIT ASSEMBLY |
Restrictions/Controls & Freight Information | NSN 6625-01-533-1471
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 061700 | ELEC APPLIANCES/INSTRUMENTS NOI |
| Less than car load rating | P | 77.5 |
| Less than truck load rating | J | 100.2 |
| Water commodity Code | 738 | unknown |
| Originating Activity Code | TK | HQ AFMC/GLSC 401 SCM/GUMB Wright-Patterson AFB, OH 45433-5000 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
