NSN 6625-01-520-7737 POWER XPLORER PX5-400, POWERXPLORERPX5400, 01-520-7737
Product Details | VOLTAGE DEVIATION MONITOR
6625-01-520-7737 An item that accepts fixed voltages from test points in another component or set, and displays them in such a manner that deviation from a predetermined voltage value is readily apparent. The display is in terms of "good" and "bad" and is not in terms of voltage values. For items that display the same or similar information that is derived from a radio frequency signal input, see MONITOR, ERROR VOLTAGE. For items that indicate voltage values in either scaler or digital form, see VOLTMETER. See also INDICATOR (as modified).20614300037Guided Missile Remote Control Systems49350070Guided Missile Maintenance, Repair, and Checkout Specialized Equipment58400032Radar Equipment, Except Airborne58500051Visible and Invisible Light Communication Equipment61100028Electrical Control Equipment66250070Electrical and Electronic Properties Measuring and Testing Instruments
Part Alternates: POWER XPLORER PX5-400, POWERXPLORERPX5400, 6625-01-520-7737, 01-520-7737, 6625015207737, 015207737
Instruments and Laboratory Equipment | Electrical and Electronic Properties Measuring and Testing Instruments
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 66 | 25 MAY 2004 | 01-520-7737 | 21746 ( MONITOR, VOLTAGE DEVIATION ) |
Drawings & Photos | NSN 6625-01-520-7737
Demand History | NSN 6625-01-520-7737
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 6625-01-520-7737 | 2008-07-198 | 1 | US |
Cross Reference | NSN 6625-01-520-7737
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| POWER XPLORER PX5-400 | 23207 | DRANETZ TECHNOLOGIES INC. DBA BASIC MEASURING INSTRUMENTS |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 6625-01-520-7737
Technical Data | NSN 6625-01-520-7737
| Characteristic | Specifications |
|---|---|
| CIRCUIT CONSTRUCTION TYPE | ELECTRON TUBE |
| AVERAGE LIFE MEASUREMENT | NOT RATED |
| OPERATING TEMP RANGE | 0.0 TO 50.0 DEG CELSIUS |
| INCLOSURE TYPE | ENCASED |
| INSTALLATION DESIGN | TOP OF CABINET/COUNTER |
| BASIC SHAPE STYLE | 1 RECTANGULAR OR SQUARE |
| OVERALL LENGTH | 12.000 INCHES NOMINAL |
| OVERALL HEIGHT | 2.500 INCHES NOMINAL |
| OVERALL WIDTH | 8.000 INCHES NOMINAL |
| SPECIAL FEATURES | INTEGRATES POWER MONITORING INSTRUMENT WITH COLOR GRAPHICAL USER INTERFACE |
| III PART NAME ASSIGNED BY CONTROLLING AGENCY | POWER QUALITY ANALYZER |
Restrictions/Controls & Freight Information | NSN 6625-01-520-7737
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Electro-static Discharge Susceptible: | A | No known Electrostatic Discharge (ESD) or Electromagnetic Interference (EMI) sensitivity |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| No Freight Information | ||
