NSN 6625-01-291-5370 90000020, T75, T-75
Product Details | NAVIGATION TEST SET
6625-01-291-5370 An item or group of items specifically designed to examine and evaluate long range, short range or tactical type navigation sets. See also TEST SET, SIGNAL GENERATOR and TEST SET, RADAR.
Part Alternates: 90000020, T75, T-75, 6625-01-291-5370, 01-291-5370, 6625012915370, 012915370
Instruments and Laboratory Equipment | Electrical and Electronic Properties Measuring and Testing Instruments
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 66 | 30 DEC 1988 | 01-291-5370 | 47412 ( TEST SET, NAVIGATION ) |
Demand History | NSN 6625-01-291-5370
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| T-75 | 2011-09-263 | 12 | |
| T-75 | 2011-09-263 | 8 |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 6625-01-291-5370
Related Products | NSN 6625-01-291-5370
Technical Data | NSN 6625-01-291-5370
| Characteristic | Specifications |
|---|---|
| TEST TYPE FOR WHICH DESIGNED | USED TO VERIFY FLIGHT READINESS OF THE MICROWAVE LANDING SYSTEM(MLS) |
| ELECTRICAL POWER SOURCE RELATIONSHIP | OPERATING |
| AC VOLTAGE RATING | 115.0 VOLTS NOMINAL |
| FREQUENCY RATING | 60.0 HERTZ MINIMUM AND 400.0 HERTZ MAXIMUM |
| PHASE | SINGLE |
| INTERNAL BATTERY ACCOMMODATION | INCLUDED |
| INCLOSURE FEATURE | SINGLE ITEM W/CARRYING CASE |
| HEIGHT | 3.750 INCHES NOMINAL |
| LENGTH | 18.000 INCHES NOMINAL |
| WIDTH | 7.080 INCHES NOMINAL |
| III SUPPLEMENTARY FEATURES | TESTS ANTENNAS, AMPLIFIERS,SPLITTERS, SWITCHING FUNCTIONS AND REVEIVER PROCESSING UNITS OF MLS AS AN OPERATIONAL SYSTEM WHILE INSTALLED AND OPERATING ON THE AIRCRAFT |
| MANUFACTURERS CODE | 92606 |
| DESIGN CONTROL REFERENCE | T-75 |
Restrictions/Controls & Freight Information | NSN 6625-01-291-5370
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | B | Munitions List Item - Mutilation (MUT) to the point of scrap required. (Formerly: Demilitarization not required. Trade Security Controls (TSCs) required at disposition.) |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 061700 | ELEC APPLIANCES/INSTRUMENTS NOI |
| Less than car load rating | P | 77.5 |
| Less than truck load rating | J | 100.2 |
| Water commodity Code | 738 | unknown |
| Originating Activity Code | SE | San Antonio Air Logistics Center Kelly AFB, TX 78241-5000 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Q | Extremely fragile items including delicate instruments. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 6625-01-291-5370
Air Force| Category | Code | Description |
|---|---|---|
| Price Validation | E | The current standard price is an estimated price.
|
| Materiel Management Aggregation Code | RH | TG:AUTO TEST EQUIPMENT/AUTO TEST SYSTEMS (ATE/ATS) (FSC RESIDUAL MMAC) |
| Budget Code | Y | variousO & M:AF centrally procured equipment items. They are separate, primary end items (other than the weapon system itself) needed by a user to perform an assigned mission. They are nonexpendable items (ERRCD NF or ND) which are not consumed in use, and they do not lose their original identity during periods of use by incorporation into, or attachment to another assembly. |
| Source of Supply | FLZ | Warner Robins Air Logistics Center Robins AFB, GA 31098-5609 |
| Agency | DF | Department of the Air Force |
| Service Organization | L | Lead Service - 22 (Repairable) |
| Reparability | S | AF Equipment Management System (AFEMS) |
| Acquisition Advice Codes | X | SEMIACTIVE ITEM-NO REPLACEMENT (NON-STOCKED ITEMS) A potentially inactive NSN which must be retained in the supply system as an item of supply because (1) stocks of the item are on hand or in use below the wholesale level and (2) the NSN is cited in equipment authorization documents TO & E, TA, TM, etc., or in-use assets are being reported. 1. Items are authorized for central procurement but not authorized for stockage at wholesale level. 2. Requisitions for in-use replacement will be authorized in accordance with individual Military Service directives. 3. Requisitions may be submitted as requirements generate. Repetitive demands may dictate an AAC change to permit wholesale stockage. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
