NSN 6625-01-050-7797 2208, 01-050-7797, 010507797
Product Details | AUDIO LEVEL METER
6625-01-050-7797 An instrument which measures the ratio of electrical power with reference to a predetermined value and is calibrated in units of sound intensity, usually decibels. The value may be expressed by means of a pointer and calibrated dial or a digital readout display. If other than audio frequency ranges, see METER, NOISE LEVEL.
Part Alternates: 2208, 6625-01-050-7797, 01-050-7797, 6625010507797, 010507797
Instruments and Laboratory Equipment | Electrical and Electronic Properties Measuring and Testing Instruments
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 66 | 13 NOV 1977 | 01-050-7797 | 16456 ( METER, AUDIO LEVEL ) |
Drawings & Photos | NSN 6625-01-050-7797
Demand History | NSN 6625-01-050-7797
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 2208 | 2024-12-348 | 22 | United States |
Cross Reference | NSN 6625-01-050-7797
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 2208 | 27591 | B-K MEDICAL SYSTEMS, INC. |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 6625-01-050-7797
Technical Data | NSN 6625-01-050-7797
| Characteristic | Specifications |
|---|---|
| MEASUREMENT RANGE | 32.0 TO 130.0 DECIBELS SINGLE INDICATOR SINGLE RANGE |
| SCALE DIVISION QUANTITY | 30 SINGLE INDICATOR SINGLE RANGE |
| FREQUENCY RESPONSE RANGE | 0.020 TO 10.000 KILOHERTZ |
| STYLE DESIGNATOR | D1 RECTANGULAR OR SQUARE |
| OVERALL HEIGHT | 51.0 MILLIMETERS NOMINAL |
| OVERALL LENGTH | 186.0 MILLIMETERS NOMINAL |
| OVERALL WIDTH | 84.0 MILLIMETERS NOMINAL |
| FURNISHED ITEMS AND QUANTITY | CARRYING CASE 1,WRIST STRAP 1,MICROPHONE 1,WINDSCREEN 1 |
| FEATURES PROVIDED | PORTABLE |
Restrictions/Controls & Freight Information | NSN 6625-01-050-7797
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| No Freight Information | ||
