NSN 6625-00-885-4146 HS3Z4828692, HS3Z-482869-2, R-330
Product Details | NULL METER
6625-00-885-4146 An electrically operated instrument having a zero point on its scale (usually located in the center thereof). It may not indicate units of electrical measurement. The value may be expressed by means of a pointer and calibrated dial or a digital readout display. When the indication shows zero, an electrical value of "zero" has been reached in the circuit. It is generally used in situations in which zero is the desired effect. Excludes AMMETER, GALVANOMETER; METER, ARBITARY SCALE; and VOLTMETER.
Part Alternates: HS3Z4828692, HS3Z-482869-2, R-330, R330, 25314828692, 2531-482869-2, 25R, 25SR, 32234828692, 3223-482869-2, 365, 4828692, 482869-2, 6314828692, 631-482869-2, 6625-00-885-4146, 00-885-4146, 6625008854146, 008854146
Instruments and Laboratory Equipment | Electrical and Electronic Properties Measuring and Testing Instruments
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 66 | 05 MAY 1972 | 00-885-4146 | 61382 ( METER, NULL ) |
Drawings & Photos | NSN 6625-00-885-4146
Demand History | NSN 6625-00-885-4146
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 6625-00-885-4146 | 2009-02-57 | 3 | DIBBS |
| R330 | 2008-01-15 | 3 | France |
Cross Reference | NSN 6625-00-885-4146
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 2531-482869-2 | 12189 | METERMASTER INC |
| 2531-482869-2 | 27197 | METERMASTER INC METERMOD DIV |
| 2531-482869-2 | 28304 | CUSTOM METERING COMPANY INC |
| 2531-482869-2 | 65092 | SOLARTRON ELECTRONICS INC WESTON INSTRUMENTS DIV |
| 25R | 55026 | SIMPSON ELECTRIC COMPANY DBA (SUB OF LAC DU FLAMBEAU BAND OF |
| 25SR | 35104 | BACH-SIMPSON LTD |
| 3223-482869-2 | 55026 | SIMPSON ELECTRIC COMPANY DBA (SUB OF LAC DU FLAMBEAU BAND OF |
| 365 | 15309 | JEWELL INSTRUMENTS, LLC DBA MODUTEC USE CAGE CODE 33005 FOR |
| 482869-2 | 3B150 | RAYTHEON TECHNICAL SERVICES COMPANY LLC |
| 482869-2 | 49956 | RAYTHEON COMPANY DBA RAYTHEON |
| 631-482869-2 | 77221 | PHAOSTRON INSTRUMENT AND ELECTRONIC COMPANY |
| HS3Z-482869-2 | 33005 | JEWELL INSTRUMENTS, LLC DBA MODUTEC |
| R-330 | 11707 | IDEAL PRECISION METER CO |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 6625-00-885-4146
Related Products | NSN 6625-00-885-4146
Technical Data | NSN 6625-00-885-4146
| Characteristic | Specifications |
|---|---|
| INSTALLATION DESIGN | PANEL |
| (NON-CORE DATA) PANEL FOR WHICH DESIGNED | MAGNETIC OR NONMAGNETIC |
| INDICATOR TYPE | DIAL W/POINTER |
| SCALE MARKING | RED BAND ALONG ENTIRE RANGE EXC 1.9 MM GREEN SEC AT ZERO CTR REF; CCW L OF CTR; ARROW AT CTR; CW RIGHT OF CTR |
| ACCURACY IN PERCENT | -2.0 TO 2.0 AT FULL SCALE SINGLE INDICATOR SINGLE RANGE |
| SCALE GRADUATION TYPE | LINEAR SINGLE INDICATOR SINGLE RANGE |
| SCALE DIVISION QUANTITY | 18 SINGLE INDICATOR SINGLE RANGE |
| POINTER COLOR | BLACK SINGLE INDICATOR SINGLE RANGE |
| DIAL SCALE MARKING COLOR | BLACK SINGLE INDICATOR SINGLE RANGE |
| BACKGROUND COLOR | WHITE SINGLE INDICATOR SINGLE RANGE |
| MOVEMENT TYPE | MOVING COIL, PERMANENT MAGNET |
| MOVEMENT SUSPENSION METHOD | JEWEL PIVOT BASE |
| CIRCUIT ATTACHMENT METHOD AND QUANTITY | 2 SOLDER LUG AND 2 THREADED STUD |
| SENSITIVITY RATING | 1.0 MILLIAMPERES |
| DIELECTRIC WITHSTANDING VOLTAGE IN VOLTS | 3000.0 |
| CIRCUIT CURRENT FOR WHICH DESIGNED | DC |
| STYLE DESIGNATOR | C1 ROUND FLUSH MTG |
| METER BODY DIAMETER BEHIND MOUNTING FLANGE | 2.800 INCHES MAXIMUM |
| METER DEPTH BEHIND MOUNTING FLANGE | 1.660 INCHES MAXIMUM |
| OVERALL DIAMETER | 3.510 INCHES MAXIMUM |
| OVERALL LENGTH | 2.850 INCHES MAXIMUM |
| MOUNTING FACILITY TYPE AND QUANTITY | 1 FLANGE AND 3 SCREW AND 3 UNTHREADED HOLE |
| MOUNTING HOLE DIAMETER | 0.143 INCHES MINIMUM AND 0.157 INCHES MAXIMUM |
| MOUNTING ARRANGEMENT STYLE | E5 THREE HOLE/STUD BOLT CIRCLE |
| MOUNTING BOLT CIRCLE DIAMETER | 3.160 INCHES NOMINAL |
| MATERIAL | STEEL CORROSION RESISTING |
| SURFACE TREATMENT | ENAMEL SEMIGLOSS |
| ENVIRONMENTAL PROTECTION | COLD RESISTANT AND HEAT RESISTANT AND SHOCK RESISTANT AND SUBMERSIBLE AND VIBRATION RESISTANT AND WATERTIGHT |
| FURNISHED ITEMS AND QUANTITY | WASHER 7; NUT 7 |
| FEATURES PROVIDED | LUMINOUS SCALE MARKING AND MAGNETIC SHIELD AND ZERO ADJUSTER |
| SPECIAL FEATURES | RUGGEDIZED; WEAPON SYSTEM ESSENTIAL |
| SPECIAL TEST FEATURES | CONFORMS TO MIL-M-10304/12,TYPE MR36W1U1DCMAR |
| CRITICALITY CODE JUSTIFICATION | FEAT |
| III FSC APPLICATION DATA | TEST SET,ELECT. EQUIP. |
Restrictions/Controls & Freight Information | NSN 6625-00-885-4146
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | Y | The item does not have a nuclear hardened feature but does have other critical feature(s) such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 136740 | METERS ELEC/PARTS |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 657 | unknown |
| Originating Activity Code | TX | Defense Supply Center Columbus Columbus, OH 43218 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 6625-00-885-4146
Air Force| Category | Code | Description |
|---|---|---|
| Budget Code | 9 | General Support DIV57X4921.070:Air Force decentrally managed expense items (ERRC XB3, XF-3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors. |
| Price Validation | N | The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
|
| Fund Code | SF | Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point. |
| Materiel Management Aggregation Code | TG | TG:AF SICA RESIDUAL MMAC-WR-ALC |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DF | Department of the Air Force |
| Service Organization | F | U.S. Air Force |
| Reparability | P | Stock Fund (except Munitions) |
| Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
