NSN 6625-00-615-4490 SG-89/UPM-68, SG89UPM68, 1022
Product Details | PULSE GENERATOR
6625-00-615-4490 An electronic device which develops a discontinuous electrical potential with an abrupt rate of change of voltage which determines the harmonic content of the pulse train. The duration of a single pulse output is relatively short compared to the time of the recurrence cycle. See also GENERATOR, SINGLE PULSE; and GENERATOR, ELECTRONIC MARKER.20358950037Miscellaneous Communication Equipment61150041Generators and Generator Sets, Electrical66250070Electrical and Electronic Properties Measuring and Testing Instruments
Part Alternates: SG-89/UPM-68, SG89UPM68, 1022, 6625-00-615-4490, 00-615-4490, 6625006154490, 006154490
Instruments and Laboratory Equipment | Electrical and Electronic Properties Measuring and Testing Instruments
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 66 | 01 JAN 1963 | 00-615-4490 | 00411 ( GENERATOR, PULSE ) |
Drawings & Photos | NSN 6625-00-615-4490
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 6625-00-615-4490
Technical Data | NSN 6625-00-615-4490
| Characteristic | Specifications |
|---|---|
| CIRCUIT CONSTRUCTION TYPE | SOLID STATE |
| FREQUENCY PER CHANNEL | 30.0 MEGAHERTZ NOMINAL OPERATING CHANNEL |
| IMPEDANCE RATING PER CHANNEL | 50.000 OHMS OPERATING CHANNEL |
| PULSE PEAK AMPLITUDE PER CHANNEL | 250.000 MILLIVOLTS OPERATING CHANNEL |
| PULSE DURATION PER CHANNEL | 30.000 MICROSECONDS NOMINAL OUTPUT CHANNEL |
| PULSE RISE TIME PER CHANNEL | 200.000 NANOSECONDS NOMINAL OUTPUT CHANNEL |
| PULSE DECAY TIME PER CHANNEL | 200.000 NANOSECONDS NOMINAL OUTPUT CHANNEL |
| POLARITY PER CHANNEL | POSITIVE OUTPUT CHANNEL NEGATIVE OUTPUT CHANNEL |
| PULSE REPETITION RATE PER CHANNEL | 200.000 PULSES PER SECOND MINIMUM OUTPUT CHANNEL 6.000 KILOPULSES PER SECOND MAXIMUM OUTPUT CHANNEL |
| SIGNAL DATA TYPE PER CHANNEL | OPERATING CHANNEL PULSE |
| CALIBRATION FUNCTION | PULSE REPETITION |
| CALIBRATED TOLERANCE IN PERCENT | -1.7 TO 1.7 |
| OUTPUT WAVE SHAPE | RECTANGULAR |
| OPERATING CONTROL METHOD | MANUAL |
| CONTROL TYPE | LOCAL |
| AVERAGE LIFE MEASUREMENT | NOT RATED |
| EXTERNAL AC OPERATING VOLTAGE IN VOLTS | 115.0 NOMINAL SINGLE VOLTAGE |
| OPERATING AC FREQUENCY IN HERTZ | 50.0 MINIMUM SINGLE VOLTAGE 420.0 MAXIMUM SINGLE VOLTAGE |
| PHASE | SINGLE |
| INCLOSURE TYPE | HERMETICALLY SEALED |
| INSTALLATION DESIGN | RACK |
| BASIC SHAPE STYLE | 1 RECTANGULAR OR SQUARE |
| OVERALL LENGTH | 20.438 INCHES NOMINAL |
| OVERALL HEIGHT | 12.219 INCHES NOMINAL |
| OVERALL WIDTH | 19.000 INCHES NOMINAL |
| IDENTIFICATION DESIGNATOR | SG-89/UPM-68-80058 |
Restrictions/Controls & Freight Information | NSN 6625-00-615-4490
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 061700 | ELEC APPLIANCES/INSTRUMENTS NOI |
| Less than car load rating | P | 77.5 |
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 653 | unknown |
| Originating Activity Code | XX | |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | ||
| Air Special Handling | Q | Extremely fragile items including delicate instruments. |
| Special Handling Code | Q | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
