NSN 6625-00-558-2324 7L12, 00-558-2324, 005582324
Product Details | ELECTRICAL-ELECTRONIC TEST EQUIPMENT PLUG-IN UNIT
6625-00-558-2324 An electronic subassembly designed to be plugged into one or more basic pieces of test equipment to extend the capabilities of the basic instrument. The basic instrument cannot function without one or more plug-in units (as required) in position.20649200058Aircraft Maintenance and Repair Shop Specialized Equipment49310062Fire Control Maintenance and Repair Shop Specialized Equipment49330057Weapons Maintenance and Repair Shop Specialized Equipment49350070Guided Missile Maintenance, Repair, and Checkout Specialized Equipment66250070Electrical and Electronic Properties Measuring and Testing Instruments66350042Physical Properties Testing and Inspection
Part Alternates: 7L12, 6625-00-558-2324, 00-558-2324, 6625005582324, 005582324
Instruments and Laboratory Equipment | Electrical and Electronic Properties Measuring and Testing Instruments
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 66 | 11 NOV 1974 | 00-558-2324 | 66495 ( PLUG-IN UNIT, ELECTRICAL-ELECTRONIC TEST EQUIPMENT ) |
Cross Reference | NSN 6625-00-558-2324
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 7L12 | 80009 | TEKTRONIX, INC. DBA TEKTRONIX |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 6625-00-558-2324
Related Products | NSN 6625-00-558-2324
Technical Data | NSN 6625-00-558-2324
| Characteristic | Specifications |
|---|---|
| UNIT TYPE | SPECTRUM ANALYZER |
| OVERALL DEPTH | 14.000 INCHES NOMINAL |
| OVERALL WIDTH | 5.500 INCHES NOMINAL |
| OVERALL HEIGHT | 5.000 INCHES NOMINAL |
| FURNISHED ITEMS | ADAPTER,CABLE,GRATICULES |
| ACCESSORY COMPONENT QUANTITY | 3 |
| ACCESSORY IDENTIFYING NUMBER | 103-0058-00 PART NO. AND 012-0113-00 PART NO. AND 337-1439-01 PART NO. |
| MANUFACTURERS CODE | 80009 |
| DESIGN CONTROL REFERENCE | 7L12 |
