NSN 6625-00-248-5396 G000141S2, R3506531, R350653-1
Product Details | PHASE SEQUENCE INDICATOR
6625-00-248-5396 An item which indicates output phase sequence of a multiphase power source. It is generally used to facilitate proper electrical phase connections between a source and a load, and may also be used to make continuity tests.
Part Alternates: G000141S2, R3506531, R350653-1, 25-501369-2, 3506531, 350653-1, 356100, 356-100, 35610G, 356-10G, 6625-00-248-5396, 00-248-5396, 6625002485396, 255013692, 002485396
Instruments and Laboratory Equipment | Electrical and Electronic Properties Measuring and Testing Instruments
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 66 | 14 NOV 1969 | 00-248-5396 | 06489 ( INDICATOR, PHASE SEQUENCE ) |
Demand History | NSN 6625-00-248-5396
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 6625-00-248-5396 | 2006-07-201 | 37 | United States |
| 6625-00-248-5396 | 2006-07-194 | 18 | DIBBS |
| 6625-00-248-5396 | 2006-06-179 | 18 | DIBBS |
| 6625-00-248-5396 | 2006-06-164 | 18 | DIBBS |
| 6625-00-248-5396 | 2006-05-146 | 18 | DIBBS |
| 6625-00-248-5396 | 2006-05-131 | 18 | DIBBS |
| 6625-00-248-5396 | 2006-02-54 | 19 | DIBBS |
| 6625-00-248-5396 | 2006-02-39 | 19 | DIBBS |
Cross Reference | NSN 6625-00-248-5396
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 25-501369-2 | 04655 | GENERAL DYNAMICS C4 SYSTEMS, INC. |
| 350653-1 | 50237 | CAE USA INC. DBA CAE USA SIMULATION PRODUCTS |
| 356-100 | 52797 | AUTOMATION PRODUCTS GROUP, INC. |
| 356-100 | 92325 | GENERAL DYNAMICS ADVANCED INFORMATION SYSTEMS INC. |
| 356-10G | 96182 | EATON CORPORATION DBA AEROSPACE & COMMERCIAL DIVISION |
| G000141S2 | 24930 | EXELIS INC. DBA RADAR, RECONNAISSANCE & UNDERSEA |
| R350653-1 | 04071 | RAYTHEON COMPANY DBA RAYTHEON |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 6625-00-248-5396
Related Products | NSN 6625-00-248-5396
Technical Data | NSN 6625-00-248-5396
| Characteristic | Specifications |
|---|---|
| CASE MATERIAL | ALUMINUM |
| ELECTRICAL CONNECTION QUANTITY | 3 |
| PRESENTATION TYPE | INDICATOR LIGHT |
| CURRENT TYPE | AC |
| AC VOLTAGE RATING | 180.0 VOLTS MINIMUM AND 220.0 VOLTS MAXIMUM |
| PHASE | THREE |
| FREQUENCY RATING | 54.0 HERTZ MINIMUM AND 66.0 HERTZ MAXIMUM |
| CONTACT QUANTITY | 3 |
| CONTACT TYPE | WIRE LEAD |
| MOUNTING FACILITY TYPE AND QUANTITY | 1 THREADED CASE |
| LENGTH | 3.750 INCHES NOMINAL |
| DIAMETER | 0.750 INCHES NOMINAL |
| FEATURES PROVIDED | MOUNTING HARDWARE |
| III FSC APPLICATION DATA | TEST SET,ELECT. EQUIP. |
Restrictions/Controls & Freight Information | NSN 6625-00-248-5396
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 109700 | LAMP OR LIGHTING FIXTURES |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 658 | unknown |
| Originating Activity Code | CX | Defense Supply Center Richmond Richmond, VA 23297-5000 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 6625-00-248-5396
Air Force
Navy| Category | Code | Description |
|---|---|---|
| Budget Code | 9 | General Support DIV57X4921.070:Air Force decentrally managed expense items (ERRC XB3, XF-3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors. |
| Price Validation | N | The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
|
| Fund Code | SF | Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point. |
| Materiel Management Aggregation Code | TG | TG:AF SICA RESIDUAL MMAC-WR-ALC |
| Source of Supply | JCD | |
| Agency | DF | Department of the Air Force |
| Service Organization | F | U.S. Air Force |
| Reparability | N | Stock Fund (except Munitions) |
| Acquisition Advice Codes | Y | TERMINAL ITEM #(NON-STOCKED ITEMS) Future procurement is not authorized. No wholesale stock is available for issue. 1. Requisitions will not be processed to the wholesale manager. 2. Internal Service/agency requisitioning may be continued in accordance with the Service/agency requisitioning policies. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | Y | TERMINAL ITEM #(NON-STOCKED ITEMS) Future procurement is not authorized. No wholesale stock is available for issue. 1. Requisitions will not be processed to the wholesale manager. 2. Internal Service/agency requisitioning may be continued in accordance with the Service/agency requisitioning policies. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
