Product Details | PHASEMETER
6625-00-099-0196 An item that indicates in electrical degrees the displacement between two or more wave forms. See also INDICATOR, PHASE SEQUENCE.20249200058Aircraft Maintenance and Repair Shop Specialized Equipment66250070Electrical and Electronic Properties Measuring and Testing Instruments
Part Alternates: M39012/16-0502 , M39012160502, M3901216502, M39012-16-502 , AN/URM-67, ANURM67, KC59416, KC-59-416 , MIL-C-39012/16 , MILC3901216, 84781800W, 847-81800W , 20101, 20-101, 6625-00-099-0196, 00-099-0196, 6625000990196, 000990196
Instruments and Laboratory Equipment | Electrical and Electronic Properties Measuring and Testing Instruments
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 66 | 01 JAN 1963 | 00-099-0196 | 21845 ( PHASEMETER ) |
Drawings & Photos | NSN 6625-00-099-0196
Demand History | NSN 6625-00-099-0196
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| M39012160502 | 2023-05-136 | 1 | United States |
| M39012160502 | 2019-10-304 | 44 | United States |
| M39012160502 | 2018-10-281 | 74 | US |
| M39012160502 | 2018-09-269 | 7 | United States |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 6625-00-099-0196
Related Products | NSN 6625-00-099-0196
Technical Data | NSN 6625-00-099-0196
| Characteristic | Specifications |
|---|---|
| INSTALLATION DESIGN | RACK |
| CIRCUIT CURRENT FOR WHICH DESIGNED | AC |
| OPERATING VOLTAGE RATING IN VOLTS | 115.0 AC NOMINAL |
| FREQUENCY RATING | 50.0 HERTZ MINIMUM AND 1000.0 HERTZ MAXIMUM |
| PHASE | SINGLE |
| STYLE DESIGNATOR | D1 RECTANGULAR OR SQUARE |
| OVERALL HEIGHT | 14.750 INCHES NOMINAL |
| OVERALL LENGTH | 19.875 INCHES NOMINAL |
| OVERALL WIDTH | 23.125 INCHES NOMINAL |
| MATERIAL | ALUMINUM |
| SURFACE TREATMENT | PAINT |
| III ENTRY DATE | 70-04-01 |
| III FUNCTIONAL CLASSIFICATION | AA-2.2 |
| III TYPE/MODEL DESIGNATION | AN/URM-67 |
| III FUNCTIONAL DESCRIPTION | MEASURES THE PHASE ANGLE BETWEEN 2 APPLIED AUDIO-FREQUENCY SIGNALS,WITHIN RANGE OF 20-20000 HZ,ACCURACY PORM 1.0 DEGREE; REQUIRED AMPLITUDE OF INPUT SIGNALS,SINUSODIAL OR NONSINUSODIAL,IS 2-30 VOLTS PEAK,EQUIVALENT TO RMS VALUES OF 1.4-21.2 VOLTS; A PANEL-MOUNTED DC METER IS EMPLOYED TO DISPLAY PHASE ANGLE BETWEEN THE 2 APPLIED VOLTAGES; PROVISION MADE FOR CONNECTING AN EXTERNAL RECORDER TO THE OUTPUT OF INSTRUMENT,SO PHASE ANGLE CAN BE RECORDED CONTINUOUS,IF DESIRED |
| III RELATIONSHIP TO SIMILAR EQUIPMENT | WHEN EXHAUSTED USE 6625009844729;INTERCHANGEABLE W/ 6625007139072 |
| III REFERENCE DATA AND LITERATURE | T.O. 33A1-13-50-1,2,4; MIL SPEC MIL-M-4918A |
| MANUFACTURERS CODE | 80058 |
| DESIGN CONTROL REFERENCE | AN/URM-67 |
