NSN 6620-00-857-5364 EFU-2/A, EFU2A, MILI26299
Product Details | RATE OF FLOW INDICATOR
6620-00-857-5364 An indicator which indicates the rate of flow of a fluid.20266200018Engine Instruments66800078Liquid and Gas Flow, Liquid Level, and Mechanical Motion Measuring Instruments
Part Alternates: EFU-2/A, EFU2A, MILI26299, MIL-I-26299, MILT0026299AMEND1TYPEEFU2A, 980720, 9807-20, 6620-00-857-5364, 00-857-5364, 6620008575364, 008575364
Instruments and Laboratory Equipment | Engine Instruments
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 66 | 01 JAN 1962 | 00-857-5364 | 16124 ( INDICATOR, RATE OF FLOW ) |
Cross Reference | NSN 6620-00-857-5364
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 9807-20 | 1K426 | MOOG INC. DBA MOOG COMPONENTS GROUP |
| 9807-20 | 99932 | MOOG INC. DBA MOOG COMPONENTS GROUP |
| EFU-2/A | 80058 | JOINT ELECTRONICS TYPE DESIGNATION SYSTEM |
| MIL-I-26299 | 81349 | MILITARY SPECIFICATIONS PROMULGATED BY MILITARY |
| MILT0026299AMEND1TYPEEFU2A | 81349 | MILITARY SPECIFICATIONS PROMULGATED BY MILITARY |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 6620-00-857-5364
Related Products | NSN 6620-00-857-5364
Technical Data | NSN 6620-00-857-5364
| Characteristic | Specifications |
|---|---|
| USAGE DESIGN | RATE OF FLOW |
| ELECTRICAL CONNECTION QUANTITY | 1 |
| ELECTRICAL CONNECTION IDENTIFYING NUMBER | MC14H-13-12PN OR EQUAVALENT |
| PRESENTATION TYPE | DIAL |
| SCALE RANGE | 0.0 TO 5000.0 POUNDS PER HOUR SINGLE INDICATOR SINGLE SCALE |
| POINTER TYPE | INDICATING SINGLE POINTER |
| INDIVIDUAL MARKING | FUEL FLOW; PPH X 1000 |
| CURRENT TYPE | AC |
| AC VOLTAGE RATING | 115.0 VOLTS NOMINAL |
| PHASE | SINGLE |
| FREQUENCY RATING | 400.0 HERTZ NOMINAL |
| CONTACT TYPE | PIN |
| MOUNTING FACILITY TYPE AND QUANTITY | 1 CLAMP |
| LENGTH | 6.125 INCHES NOMINAL |
| DIAMETER | 2.000 INCHES NOMINAL |
| DIAL OUTSIDE DIAMETER | 1.750 INCHES NOMINAL |
| FEATURES PROVIDED | HERMETICALLY SEALED CASE |
| SPECIAL FEATURES | CASE PER MS33639; DIAL INCLUDES ELECTRICAL ZERO REFERENCE MARK; CASE INCLUDES FILLER TUBE; WEIGHT 1.5 LBS; INTEGRAL RED LIGHTING |
| III SUPPLEMENTARY FEATURES | TECH ORDER 5L6-2-10-34 |
| III PART NAME ASSIGNED BY CONTROLLING AGENCY | FUEL MASS FLOWMETER INDICATOR |
| MANUFACTURERS CODE | 81349 |
| NON-DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | MIL-I-26299 |
Restrictions/Controls & Freight Information | NSN 6620-00-857-5364
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | B | Munitions List Item - Mutilation (MUT) to the point of scrap required. (Formerly: Demilitarization not required. Trade Security Controls (TSCs) required at disposition.) |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Electro-static Discharge Susceptible: | A | No known Electrostatic Discharge (ESD) or Electromagnetic Interference (EMI) sensitivity |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 121570 | GAGES AIR LIQUID LEVEL PRESSURE |
| Less than car load rating | J | 100.2 |
| Less than truck load rating | J | 100.2 |
| Water commodity Code | 652 | unknown |
| Originating Activity Code | XX | |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | Z | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 6620-00-857-5364
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 7R | Aeronautical Depot Level Repairable Spares Naval Inventory Control Point, Philadelphia |
| Special Material ID | GT | CARGO/TRANSPORTAIRCRAFT(T39) |
| Issue Repair, or Requisition | AR | Repairable item subject to centrally managed rework program at designated sites. Mandatory turn-in of item required except when initial issue or replacement of surveyed item is involved. |
| Special Material Content | 9 | Non-Hazardous or Non-Sensitive Item, does not require hazardous or special handling, packaging or precautions |
| Source of Supply | NRP | NAVICP-ERP 700 Robbins Avenue Philadelphia, PA 19111-5098 |
| Agency | DN | Department of the Navy |
| Service Organization | L | Lead Service - 22 (Repairable) |
| Reparability | H | Depot Level Reparable |
| Acquisition Advice Codes | V | TERMINAL ITEM # Identifies items in stock, but future procurement is not authorized. Requisitions may continue to be submitted until stocks are exhausted. Preferred item National Stock Number is normally provided by application of the phrase: When Exhausted Use (NSN). Requisitions will be submitted in accordance with IMM/Service requisitioning procedures as applicable. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
