NSN 6610-01-583-7787 F3001, 3001130090, 3001-1300-90
Product Details | DATA ACQUISITION UNIT
6610-01-583-7787 A specifically designed item which receives analog and/or digital signals from a variety of sources such as strain gages, thermocouples, transducers, manual data entry devices and the like and processes them to provide a useful output for monitoring, recording internally or externally, and/or analyzing etc. It may provide for single or multiple inputs and/or outputs.20458250043Radio Navigation Equipment, Except Airborne66100018Flight Instruments66250070Electrical and Electronic Properties Measuring and Testing Instruments70250036ADP Input/Output and Storage Devices
Part Alternates: F3001, 3001130090, 3001-1300-90, 6610-01-583-7787, 01-583-7787, 6610015837787, 015837787
Instruments and Laboratory Equipment | Flight Instruments
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 66 | 06 APR 2010 | 01-583-7787 | 50835 ( DATA ACQUISITION UNIT ) |
Drawings & Photos | NSN 6610-01-583-7787
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 6610-01-583-7787
Technical Data | NSN 6610-01-583-7787
| Characteristic | Specifications |
|---|---|
| UNPACKAGED UNIT WIDTH | 6.19 INCHES NOMINAL |
| UNPACKAGED UNIT HEIGHT | 7.64 INCHES NOMINAL |
| UNPACKAGED UNIT LENGTH | 14.20 INCHES NOMINAL |
| MOUNTING TYPE | BASE, SHOCK MOUNT |
| END ITEM IDENTIFICATION | ROYAL AIR FORCE E-3D AIRCRAFT |
| PART NAME ASSIGNED BY CONTROLLING AGENCY | DIGITAL FLIGHT DATA ACQUISITION UNIT |
| FUNCTIONAL DESCRIPTION | RECEIVES ANALOG, DISCRETE, AND DIGITAL PARAMETERS FROM ONBOARD SENSORS AND AVIONIC EQUIPMENT. THEN FORMATS AND ROUTES DATA TO THE FLIGHT DATA RECORDER |
| DIRECT CURRENT VOLTAGE RATING IN VOLTS | 28.0 |
| POWER SOURCE | EXTERNAL |
| REFERENCE DATA AND LITERATURE | L3 MANUAL 165E4064-90 |
Restrictions/Controls & Freight Information | NSN 6610-01-583-7787
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | D | Munitions List Item or Commerce Control List Item. Demilitarization required. Total destruction of the item and components so as to preclude restoration or repair to a usable condition by melting, cutting, tearing, scratching, crushing, breaking, punching, neutralizing, etc. (As an alternate, burial or deep water dumping may be used when coordinated with the DoD Demilitarization Program Office.) |
| Electro-static Discharge Susceptible: | A | No known Electrostatic Discharge (ESD) or Electromagnetic Interference (EMI) sensitivity |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| No Freight Information | ||
