NSN 6515-01-356-7066 F92B163, 92-2-19-4 FS , 922194FS
Product Details | POWER BONE SAW BLADE
6515-01-356-7066 A thin configurated strip of steel with a continuous series of cutting teeth along one edge. Designed for all methods of power operations and longitudinal hip and tibial osteomies, including small and large bone orthopedic procedures. Excludes BLADE, BONE SAW, PNEUMATIC.
Part Alternates: F92B163, 92-2-19-4 FS , 922194FS, 27788100, 277-88-100, 6515-01-356-7066, 01-356-7066, 6515013567066, 013567066
Medical, Dental, and Veterinary Equipment and Supplies | Medical and Surgical Instruments, Equipment, and Supplies
Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
---|---|---|---|
65 | 09 APR 1992 | 01-356-7066 | 38138 ( BLADE, BONE SAW, POWER ) |
Request a Quote
What Our Customers Say
Compare
NSNs for Compare ( up to 4 ): Add 6515-01-356-7066
Related Products | NSN 6515-01-356-7066
Technical Data | NSN 6515-01-356-7066
Characteristic | Specifications |
---|---|
DESIGN DESIGNATION | STRYKER |
SPECIFIC USE | DEEP CUTTING LARGE BONES |
MATERIAL AND LOCATION | STEEL CORROSION RESISTING OVERALL |
STYLE DESIGNATOR | A27B SAGITTAL SAW, LARGE BONE |
BLADE WIDTH | 1.000 INCHES NOMINAL |
TEETH QUANTITY | 16 |
THICKNESS | 0.64 MILLIMETERS NOMINAL |
FEATURES PROVIDED | STERILE AND REUSABLE |
SPECIAL FEATURES | CUTTING EDGE 25.40 MM; CUT DEPTH 60.8 MM |
Restrictions/Controls & Freight Information | NSN 6515-01-356-7066
Category | Code | Description |
---|---|---|
Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
Precious Metals Indicator Code: | A | Item does not contain precious metal |
Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
Category | Code | Description |
---|---|---|
NMF Description | 056680 | DENTAL/MEDICAL/SURG INST R MACHINE |
Less than car load rating | ||
Less than truck load rating | F | 150.0 |
Water commodity Code | 534 | unknown |
Originating Activity Code | KX | Defense Supply Center Philadelphia Philiadelphia, PA 19101 |
Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
Air Commodity | M | Medical supplies, equipment, samples records, etc. |
Air Special Handling | Z | No special handling required. |
Special Handling Code | 9 | unknonwn |
HAZMAT | ||
Type of Cargo | Z | No special type of cargo code applicable |
