NSN 6240-00-295-1184 NW14838, S1034, S-1034

Product Details | INCANDESCENT LAMP

6240-00-295-1184 An item whose principal purpose is to produce light from a glowing filament(s). It includes metal backed and reflecting types, seal beam and flood types. It may include an integral filament shield to control and/or modify its illumination pattern.

Part Alternates: NW14838, S1034, S-1034, B6A13465A, CM1034, GM454645, W1034, W-L-00111/58, WL0011158, PB6A13465A, PL1034, R 11078, R11078, 72031, 809725, 870423, 87-0423, 967697R91, 99238, 1034, 14838, 151567, 1521, 156367, 35051, 424MBR2, 454645, 5M6724, 6240-00-295-1184, 00-295-1184, 6240002951184, 002951184

Lighting Fixtures and Lamps | Electric Lamps

Supply Group (FSG)	NSN Assign.	NIIN	Item Name Code (INC)
62	01 JAN 1963	00-295-1184	00727 ( LAMP, INCANDESCENT )

Drawings & Photos | NSN 6240-00-295-1184

Part Number	Request Date	QTY	Origin
1034	2018-09-260	2	Nigeria
1034	2018-03-73	4	United States
1034	2017-01-10	10	US
6240-00-295-1184	2016-01-14	38671	DIBBS
6240-00-295-1184	2016-01-06	38671	DIBBS
6240-00-295-1184	2013-04-92	18919	DIBBS
6240-00-295-1184	2013-02-55	14827	DIBBS
6240-00-295-1184	2013-01-23	8346	DIBBS
1034	2011-05-132	9
1034	2011-04-107	9

Cross Reference | NSN 6240-00-295-1184

Part Number	Cage Code	Manufacturer
1034	08108	LAMP INDUSTRY FOR USE WITH INDUSTRY
1034	08805	GENERAL ELECTRIC COMPANY DBA GE
1034	08806	GENERAL ELECTRIC CO MINIATURE LAMP PRODUCTS DEPT
1034	52656	DAYCOA INC
1034	62607	PHILIPS ELECTRONICS NORTH AMERICA CORPORATION
1034	80204	AMERICAN NATIONAL STANDARDS INSTITUTE, INCORPORATED
1034	92966	GTE PRODUCTS CORP LIGHTING PRODUCTS GROUP HILLSBORO
1034	94988	COOPER INDUSTRIES INC CHAMPION AVIATION PRODUCTS
1034	D9182	BOSCH REXROTH GMBH LOHMANN +STOLTERFOHT
14838	44185	NMC/WOLLARD, INC.
151567	12204	DAIMLER CHRYSLER
151567	18113	CHRYSLER CORP HAMTRAMCK ASSEMBLY
1521	75175	CONCORD INSTRUMENTS CORP
156367	12204	DAIMLER CHRYSLER
35051	10695	TAYLOR-DUNN CORPORATION DBA METRO CROWN INTERNATIONAL
424MBR2	05415	LINDE LIFT TRUCK CORP.
424MBR2	556A6	LINDE MATERIAL HANDLING NORTH AMERICA CORP
454645	24617	GENERAL MOTORS CORP
454645	30379	EUCLID INC
454645	31007	NAVISTAR INTL CORP
454645	73331	GENERAL MOTORS CORP FISHER GUIDE DIV
454645	7X677	GENERAL MOTORS LLC DBA GENERAL MOTORS
454645	89346	NAVISTAR INTL CORP TRUCK BR
454645	97907	TEREX CORP
454645	99343	CHRYSLER CORP ENGINE AND COMPONENTS SALES
5M6724	11083	CATERPILLAR INC. DBA CATERPILLAR
72031	95097	LITTLE GIANT CRANE AND SHOVEL INC
809725	15586	CUSHMAN INC A RANSOM CO
87-0423	19397	BAE SYSTEMS INFORMATION AND ELECTRONIC SYSTEMS INTEGRATION INC.
87-0423	63409	TREMETRICS INC DIV OF FINNIGAN
967697R91	31007	NAVISTAR INTL CORP
99238	30076	NACCO MATERIALS HANDLING GROUP INC DBA HYSTER
B6A13465A	23040	FORD MOTOR CO FORD PARTS AND SERVICE DIV
CM1034	71744	CHICAGO MINIATURE LIGHTING LLC DBA CHICAGO MINIATURE OPTOELECTRON
GM454645	34623	AM GENERAL, LLC
NW14838	44185	NMC/WOLLARD, INC.
PB6A13465A	23040	FORD MOTOR CO FORD PARTS AND SERVICE DIV
PB6A13465A	57526	FORD MOTOR CO
PL1034	58451	PRECISION LAMP INC
R 11078	10988	CNH INDUSTRIAL AMERICA LLC
S-1034	58815	SHOKAI FAR EAST LTD.
W-L-00111/58	81348	FEDERAL SPECIFICATIONS PROMULGATED BY GENERAL SERVICES
W1034	D9182	BOSCH REXROTH GMBH LOHMANN +STOLTERFOHT

Request a Quote

What Our Customers Say

Thank you very much for the excellent service and professional customer care.

Ernie G. Honeywell

The service was excellent. I can think of no improvements to date that you can make regarding internet sales.

John L. Raytheon

The representative for WBParts was efficient & handled our request in a timely & professional manner.

Karen G. General Dynamics

Tried two other sources, neither of them responded, was all done online, never spoke to anyone.

Rex S. US Airforce

The response is quick and the price is often very good. We are completely satisfied.

Patricia S. NASA

Compare

NSNs for Compare ( up to 4 ): Add 6240-00-295-1184

Compare

Related Products | NSN 6240-00-295-1184

6240-00-295-1185, 6240-00-295-1186, 6240-00-295-1187, 6240-00-295-1368, 6240-00-295-1377

Technical Data | NSN 6240-00-295-1184

Characteristic	Specifications
BASE STYLE	A21A DOUBLE CONTACT BAYONET CANDELABRA INDEXING
BULB STYLE	B22 S
BULB DESIGNATOR	S-8
OVERALL LENGTH	2.000 INCHES MAXIMUM
BULB LIGHT TRANSMISSION CHARACTERISTIC	TRANSPARENT
EMITTED LIGHT CHARACTERISTIC	COLORLESS
FILAMENT DESIGNATION	C-6 AND C-6
WATTAGE RATING	23.040 WATTS AND 8.260 WATTS
VOLTAGE RATING	12.800 VOLTS NOMINAL AND 14.000 VOLTS NOMINAL
CURRENT RATING FOR WHICH DESIGNED	1.800 AMPERES NOMINAL AND 0.590 AMPERES NOMINAL
LIGHT OUTPUT RATING	32.000 SPHERICAL CANDLEPOWER NOMINAL AND 3.000 SPHERICAL CANDLEPOWER NOMINAL SINGLE RATING
RATED AVERAGE LIFE	HOURS
AVERAGE LIFE RATING IN HOURS	200.0 AND 5000.0
BURNING POSITION	ANY ACCEPTABLE
FILAMENT HEAVY DUTY SERVICE RATING	NOT RATED
LIGHT CENTER LENGTH	1.250 INCHES NOMINAL
III END ITEM IDENTIFICATION	HELICOPTER, USCG SEARCH AND RESCUE, HH-60J; WHIDBEY ISLAND CLASS LSD; TRUCK, FIRE/CRASH P2; FORRESTAL CLASS CV; HELICOPTER, SEARCH AND RESCUE, HH-60H; SUPPLY CLASS AOE; NIMITZ CLASS CVN; SHIPBOARD MATERIAL HANDLING EQUIPMENT (MHE); WASP CLASS LHD; HELICOPTER, SEA KING H-3; HELICOPTER, MH-53E; HELICOPTER, CARRIER BASED ASW, SH-60F; HELICOPTER, ADVANCE ATTACK, AH-1W; TRIDENT AUXILIARY SYSTEMS
MANUFACTURERS CODE	81348
NON-DEFINITIVE GOVERNMENT SPEC/STD REFERENCE	W-L-00111/58

Restrictions/Controls & Freight Information | NSN 6240-00-295-1184

Restrictions
Freight

Category	Code	Description
Shelf-Life Code:	0	Nondeteriorative
Hazardous Material Indicator Code	P	There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product
Demilitarization Code:	A	Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required.
Controlled Inventory Item Code:	U	UNCLASSIFIED
Precious Metals Indicator Code:	A	Item does not contain precious metal
Criticality Code:	X	The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application.

Category	Code	Description
NMF Description	109550	LAMPS(BULBS) ELEC INCANDESCENT NOI
Less than car load rating
Less than truck load rating	F	150.0
Water commodity Code	761	unknown
Originating Activity Code	XX
Air Dimension Code	A	Shipment is not a consolidation and does not exceed 72 inches in any dimension.
Air Commodity	H	Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc.
Air Special Handling	Z	No special handling required.
Special Handling Code	9	unknonwn
HAZMAT
Type of Cargo	Z	No special type of cargo code applicable

Management | NSN 6240-00-295-1184

Category	Code	Description
Materiel Category and Inventory Manager	J	Ground Forces Support Materiel (DLA/GSA Items)
Appropriation and Budget Activity	2	Stock Fund Secondary Items
Management Inventory Segment	2	NONREPARABLE ITEMS (Exclusive of Insurance and Provisioning Items). This code will be used to identify items which are not reparable.
Specific Group/Generic Code	0	Medical Materiel
Weapons Systems/End Item or Homogeneous Group	00	DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
Accounting Requirements Code	X	Expendable item. An item of Army property coded with an ARC of ?X? in the AMDF. Expendable items require no formal accountability after issue from a stock record account. Commercial and fabricated items similar to items coded ?X? in the AMDF are considered expendable items.
Source of Supply	SMS	Defense Logistics Agency Enterprise Business Systems
Agency	DA	Department of the Army
Service Organization	A	U.S. Army
Reparability	Z	This is a nonreparable item. If condemned or economically unserviceable, then dispose at the level authorized replace the item.
Acquisition Advice Codes	Z	INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures.
Controlled Item Code	U	UNCLASSIFIED
Shelf Life Code	0	Nondeteriorative
Purchasing	QTY UOM	1 EA : Each

Category	Code	Description
Budget Code	9	General Support DIV57X4921.070:Air Force decentrally managed expense items (ERRC XB3, XF-3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors.
Fund Code	SF	Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point.
Materiel Management Aggregation Code	SX	SX:AF SICA RESIDUAL MMAC-OC-ALC
Price Validation	V	The current standard price has been validated. The item has been analyzed in conjunction with the Zero Overpricing Program and is in the accepted price range. The item was procured under open competition and under the competitive arena the price is considered fair and reasonable. ZOP or Standard price challenges are permissible but must be supported by adequate justification.
Source of Supply	SMS	Defense Logistics Agency Enterprise Business Systems
Agency	DF	Department of the Air Force
Service Organization	F	U.S. Air Force
Reparability	N	Stock Fund (except Munitions)
Acquisition Advice Codes	Z	INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures.
Controlled Item Code	U	UNCLASSIFIED
Shelf Life Code	0	Nondeteriorative
Purchasing	QTY UOM	1 EA : Each

Category	Code	Description
Stores Account Code	1	Marine Corps Stock Fund Account Item.
Combat Essentiality Code	5	Critical Repair Part to a Combat Essential End Item. Those parts or components whose failure in a combat essential end item will render the end item inoperative or reduce its effectiveness below the minimum acceptable level of efficiency.
Materiel Management Code	B	All CommoditiesDefense Logistics Agency, (DLA,)
Echelon Management Code	2	ICP/DSSC Marine Corps-managed Recoverability Code D items and Defense Logistics Agency (DLA)/TACOM/GSA) items which the integrated manager has not decontrolled.
Source of Supply	SMS	Defense Logistics Agency Enterprise Business Systems
Agency	DM	U.S. Marine Corps
Service Organization	M	U.S. Marine Corps
Reparability	Z	Nonreparable item. When unserviceable, condemn and dispose at the level indicated by the first digit of the maintenance code.
Acquisition Advice Codes	Z	INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures.
Controlled Item Code	U	UNCLASSIFIED
Shelf Life Code	0	Nondeteriorative
Purchasing	QTY UOM	1 EA : Each

Category	Code	Description
Cognizance Codes	9B	Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg
Source of Supply	SMS	Defense Logistics Agency Enterprise Business Systems
Agency	DN	Department of the Navy
Service Organization	N	U.S. Navy
Acquisition Advice Codes	Z	INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures.
Controlled Item Code	U	UNCLASSIFIED
Shelf Life Code	0	Nondeteriorative
Purchasing	QTY UOM	1 EA : Each
