NSN 6220-01-259-9016 ST70D271, ST70D27-1, 80384
Product Details | HEADLIGHT
6220-01-259-9016 An item conforming to LIGHT (1) which, when installed on a vehicle, projects a forward-focused beam of light to a limited area and facilitates operation during periods of darkness. The item must include provisions for mounting on a vehicle. Excludes LAMP (as modified).
Part Alternates: ST70D271, ST70D27-1, 80384, 22593, 6220-01-259-9016, 01-259-9016, 6220012599016, 012599016
Lighting Fixtures and Lamps | Electric Vehicular Lights and Fixtures
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 62 | 23 JUL 1987 | 01-259-9016 | 22218 ( HEADLIGHT ) |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 6220-01-259-9016
Related Products | NSN 6220-01-259-9016
Technical Data | NSN 6220-01-259-9016
| Characteristic | Specifications |
|---|---|
| SHAPE | TAPERED |
| OVERALL DIAMETER | 6.310 INCHES NOMINAL |
| OVERALL LENGTH | 3.880 INCHES NOMINAL |
| VOLTAGE RATING IN VOLTS | 12.0 DC NOMINAL |
| MATERIAL | RUBBER NATURAL BODY |
| MATERIAL DOCUMENT AND CLASSIFICATION | NO.66 FED STD SINGLE MATERIAL RESPONSE BODY |
| SURFACE TREATMENT | CHROMIUM BODY |
| LAMP TYPE ACCOMMODATED AND QUANTITY | 1 INCANDESCENT |
| LAMP BASE TYPE ACCOMMODATED | THREE SCREW TERMINALS |
| MOUNTING METHOD | THREADED STUD |
| TERMINAL TYPE AND QUANTITY | 1 WIRE LEAD |
| WIRING PROVISION METHOD | INDIVIDUAL WIRE |
| WIRING PROVISION LENGTH | ANY ACCEPTABLE SINGLE PROVISION |
| ILLUMINATION DIRECTING DEVICE TYPE | INTERNAL REFLECTOR |
| HAZARDOUS LOCATIONS/ENVIRONMENTAL PROTECTION | ANY ACCEPTABLE |
| FURNISHED ITEMS AND QUANTITY | 1 LAMP |
| SPECIAL FEATURES | 1/2 INCH THREADED STUD |
| III END ITEM IDENTIFICATION | MISSILE,MX PEACEKEEPER |
Restrictions/Controls & Freight Information | NSN 6220-01-259-9016
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 017870 | AUTO ASSEMBLIES/DEVICE LIGHT |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 585 | unknown |
| Originating Activity Code | CH | Defense Supply Center Richmond Richmond, VA 23297 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 6220-01-259-9016
Air Force| Category | Code | Description |
|---|---|---|
| Budget Code | 9 | General Support DIV57X4921.070:Air Force decentrally managed expense items (ERRC XB3, XF-3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors. |
| Price Validation | N | The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
|
| Fund Code | SF | Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point. |
| Materiel Management Aggregation Code | SX | SX:AF SICA RESIDUAL MMAC-OC-ALC |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DF | Department of the Air Force |
| Service Organization | F | U.S. Air Force |
| Reparability | N | Stock Fund (except Munitions) |
| Acquisition Advice Codes | J | NOT STOCKED, CENTRALLY PROCURED # (NON-STOCKED ITEMS) IMM/Service centrally managed but not stocked item. Procurement will be initiated only after receipt of a requisition. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
