NSN 6220-00-669-6153 15023, 15032, 225A WITH BRACKET NO. 82-7 AND
Product Details | SPOTLIGHT
6220-00-669-6153 An item which conforms to Light (1), and is designed to project a sharply defined conical beam of light for high intensity illumination of a relatively nearby object(s). Includes items which can be adjusted to function as a FLOODLIGHT, ELECTRIC. See also FLOODLIGHT, ELECTRIC; LIGHT, PHOTOGRAPHIC and SEARCHLIGHT.2056210000062200038Electric Vehicular Lights and Fixtures62300045Electric Portable and Hand Lighting Equipment65150057Medical and Surgical Instruments, Equipment, and Supplies67600038Photographic Equipment and Accessories
Part Alternates: 15023, 15032, 225A WITH BRACKET NO. 82-7 AND, 225A-W/82-BRKT6461-63B MD4CXCX87, 225AW82BRKT646163BMD4CXCX87, 225AWITHBRACKETNO827AND, 2EH900, 3196F4, 64000M, 6400-0M, 6220-00-669-6153, 00-669-6153, 6220006696153, 006696153
Lighting Fixtures and Lamps | Electric Vehicular Lights and Fixtures
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 62 | 01 JAN 1963 | 00-669-6153 | 00521 ( SPOTLIGHT ) |
Demand History | NSN 6220-00-669-6153
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 15023 | 2020-09-252 | 100 | United States |
| 6220-00-669-6153 | 2011-09-245 | 5 | DIBBS |
| 6220-00-669-6153 | 2009-04-102 | 1 | DIBBS |
| 6220-00-669-6153 | 2008-11-310 | 1 | DIBBS |
| 6220-00-669-6153 | 2008-01-25 | 20 | DIBBS |
| 6220-00-669-6153 | 2008-01-07 | 1 | DIBBS |
| 6220-00-669-6153 | 2007-06-175 | 1 | DIBBS |
| 6220-00-669-6153 | 2007-02-34 | 6 | DIBBS |
Cross Reference | NSN 6220-00-669-6153
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 15023 | 78977 | UNITY MANUFACTURING CO |
| 15032 | 78977 | UNITY MANUFACTURING CO |
| 225A WITH BRACKET NO. 82-7 AND | 78977 | UNITY MANUFACTURING CO |
| 225A-W/82-BRKT6461-63B MD4CXCX87 | 78977 | UNITY MANUFACTURING CO |
| 2EH900 | 45152 | OSHKOSH CORPORATION |
| 3196F4 | 45152 | OSHKOSH CORPORATION |
| 6400-0M | 78977 | UNITY MANUFACTURING CO |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 6220-00-669-6153
Technical Data | NSN 6220-00-669-6153
| Characteristic | Specifications |
|---|---|
| SHAPE | TAPERED |
| OVERALL DIAMETER | 6.500 INCHES NOMINAL |
| OVERALL LENGTH | 5.062 INCHES NOMINAL |
| VOLTAGE RATING IN VOLTS | 12.0 DC NOMINAL |
| MATERIAL | COPPER ALLOY BODY |
| LAMP TYPE ACCOMMODATED AND QUANTITY | 1 INCANDESCENT |
| LAMP BASE TYPE ACCOMMODATED | TWO SCREW TERMINALS |
| LENS TYPE AND QUANTITY | 1 PLANO CONVEX |
| LENS SURFACE CONDITION | SMOOTH BACK SMOOTH FACE |
| LENS COLOR | BLUE |
| LENS TRANSPARENCY | TRANSPARENT |
| MOUNTING METHOD | BRACKET |
| TERMINAL TYPE AND QUANTITY | 1 WIRE LEAD |
| WIRING PROVISION METHOD | INDIVIDUAL WIRE |
| WIRING PROVISION LENGTH | ANY ACCEPTABLE SINGLE PROVISION |
| LIGHT BEAM MOTION | FIXED |
| LAMP PROTECTION DEVICE | CLOSED END WIRE GUARD |
| FURNISHED ITEMS AND QUANTITY | 1 LAMP |
| MANUFACTURERS CODE | 78977 |
| DESIGN CONTROL REFERENCE | 15032 |
Restrictions/Controls & Freight Information | NSN 6220-00-669-6153
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 109110 | FLASHLIGHTS/SEARCHLIGHTS ETC ELEC |
| Less than car load rating | ||
| Less than truck load rating | M | 85.0 |
| Water commodity Code | 658 | unknown |
| Originating Activity Code | XX | |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 6220-00-669-6153
Army| Category | Code | Description |
|---|---|---|
| Materiel Category and Inventory Manager | J | Ground Forces Support Materiel (DLA/GSA Items) |
| Appropriation and Budget Activity | 2 | Stock Fund Secondary Items |
| Management Inventory Segment | 2 | NONREPARABLE ITEMS (Exclusive of Insurance and Provisioning Items). This code will be used to identify items which are not reparable. |
| Specific Group/Generic Code | 0 | Medical Materiel |
| Weapons Systems/End Item or Homogeneous Group | 00 | DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item |
| Accounting Requirements Code | X | Expendable item. An item of Army property coded with an ARC of ?X? in the AMDF. Expendable items require no formal accountability after issue from a stock record account. Commercial and fabricated items similar to items coded ?X? in the AMDF are considered expendable items. |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DA | Department of the Army |
| Service Organization | A | U.S. Army |
| Reparability | Z | This is a nonreparable item. If condemned or economically unserviceable, then dispose at the level authorized replace the item. |
| Acquisition Advice Codes | L | LOCAL PURCHASE # (NON-STOCKED ITEMS) Defense Logistics Agency (DLA)/GSA/Service/Agency-managed items authorized for local purchase as normal means of support at base, post, camp or station level. Item not stocked in wholesale distribution system of IMM/Service/Agency ICP. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
