NSN 6220-00-151-9607 9S4378LALT7, 00-151-9607, 001519607
Product Details | MARINE NAVIGATIONAL LIGHT
6220-00-151-9607 A light specifically designed to be mounted on a marine craft to indicate its position in motion or at rest, its speed and/or its direction of travel.20262200038Electric Vehicular Lights and Fixtures62600031Nonelectrical Lighting Fixtures
Part Alternates: 9S4378LALT7, 6220-00-151-9607, 00-151-9607, 6220001519607, 001519607
Lighting Fixtures and Lamps | Electric Vehicular Lights and Fixtures
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 62 | 01 JAN 1963 | 00-151-9607 | 00519 ( LIGHT, NAVIGATIONAL, MARINE ) |
Demand History | NSN 6220-00-151-9607
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 6220-00-151-9607 | 2023-12-345 | 1125 | VN |
Cross Reference | NSN 6220-00-151-9607
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 9S4378LALT7 | 80064 | NAVAL SHIP SYSTEMS COMMAND |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 6220-00-151-9607
Related Products | NSN 6220-00-151-9607
Technical Data | NSN 6220-00-151-9607
| Characteristic | Specifications |
|---|---|
| OVERALL DIAMETER | 5.750 INCHES NOMINAL |
| OVERALL LENGTH | 7.000 INCHES NOMINAL |
| VOLTAGE RATING IN VOLTS | 115.0 AC NOMINAL |
| MATERIAL | COPPER ALLOY BODY |
| SURFACE TREATMENT | ENAMEL BODY |
| LAMP TYPE ACCOMMODATED AND QUANTITY | 1 INCANDESCENT |
| LAMP BASE TYPE ACCOMMODATED | DOUBLE CONTACT BAYONET CANDELABRA |
| LENS TYPE AND QUANTITY | 1 TUBULAR |
| LENS SURFACE CONDITION | SMOOTH BACK FRESNEL FACE |
| LENS COLOR | GREEN |
| LENS TRANSPARENCY | TRANSPARENT |
| MOUNTING METHOD | STUD |
| ILLUMINATION DIRECTING DEVICE TYPE | INTERNAL SHIELD |
| NOMINAL VISIBILITY ARC IN DEG | 112.5 HORIZONTAL |
| SPECIAL FEATURES | INNER FACE OF SHIELD CHROME PLATED |
| REFERENCE NUMBER DIFFERENTIATING CHARACTERISTICS | AS MODIFIED BY PAC AEXD |
| MANUFACTURERS CODE | 80064 |
| DESIGN CONTROL REFERENCE | 9S4378LALT7 |
Restrictions/Controls & Freight Information | NSN 6220-00-151-9607
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 017870 | AUTO ASSEMBLIES/DEVICE LIGHT |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 585 | unknown |
| Originating Activity Code | XX | |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 6220-00-151-9607
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | F | FABRICATE OR ASSEMBLE # (NON-STOCKED ITEMS) National Stock Numbered items fabricated or assembled from raw materials and finished products as the normal method of support. Procurement and stockage of the items are not justified because of low usage or peculiar installation factors. Distinctions between local or centralized fabricate/assemble capability are identified by the Source of Supply Modifier in the Source of Supply Column of the Service Management Data Lists. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
