NSN 6150-00-665-9924 006659924
Product Details | STORAGE BATTERY LEAD
6150-00-665-9924 A definite continuous length of electrical conductor of stranded, braided, or laminated construction. Both ends must be terminated and at least one end must have a lug terminal specifically designed for connection to a storage battery. It may be insulated or uninsulated and may also include an outer protecting sleeve or conduit. For leads of this nature with other types of terminals see LEAD, ELECTRICAL. Excludes LEAD, IGNITION, ENGINE; and LEAD, ENGINE.
Part Alternates: 006659924
Electric Wire, and Power and Distribution Equipment | Batteries, Rechargeable
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 61 | 00-665-9924 | 16129 ( LEAD, STORAGE BATTERY ) |
Drawings & Photos | NSN 6140-00-665-9924
Demand History | NSN 6150-00-665-9924
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 80011 | 2022-07-194 | 1 | United States |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 6150-00-665-9924
Technical Data | NSN 6150-00-665-9924
| Characteristic | Specifications |
|---|---|
| CONDUCTOR FORM | STRANDED SINGLE CONDUCTOR |
| MATERIAL | COPPER CORE CONDUCTOR SINGLE CONDUCTOR |
| SURFACE TREATMENT | TIN CORE CONDUCTOR SINGLE CONDUCTOR |
| ROUND CONDUCTOR SIZE | 0000 AWG SINGLE CONDUCTOR |
| STRAND QUANTITY PER CONDUCTOR | 2109 SINGLE CONDUCTOR |
| STRAND AWG SIZE PER CONDUCTOR | 30 SINGLE CONDUCTOR |
| TERMINATION TYPE | TERMINAL STORAGE BATTERY BOTH ENDS FIRST CONDUCTOR |
| TERMINAL LUG STYLE | 4 RIGHT ANGLE BOLT CLAMP 1ST END SINGLE CONDUCTOR 4 RIGHT ANGLE BOLT CLAMP 2ND END SINGLE CONDUCTOR |
| TERMINAL POLARITY | NEGATIVE BOTH ENDS SINGLE CONDUCTOR |
| CENTER TO CENTER DISTANCE BETWEEN TERMINAL HOLES | 16.750 INCHES NOMINAL |
| MANUFACTURERS CODE | 66544 |
| DESIGN CONTROL REFERENCE | 80011 |
Restrictions/Controls & Freight Information | NSN 6150-00-665-9924
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Category | Code | Description |
|---|---|---|
| No Freight Information | ||
