NSN 6135-00-057-2005 VS131, WB101, 15B
Product Details | NONRECHARGEABLE BATTERY
6135-00-057-2005 A battery, composed of two or more cells forming a single unit, which is not rechargeable and whose electrolyte generally is not in fluid form. For batteries which are recargeable, see BATTERY (1), STORAGE. For items which are composed of a single cell, see CELL BATTERY. Excludes BATTERY, WATER-ACTIVATED.20213770056Cartridge and Propellant Actuated Devices and Components61350026Batteries, Nonrechargeable
Part Alternates: VS131, WB101, 15B, 5156SC, 6708, 708, 778, M708, 6135-00-057-2005, 00-057-2005, 6135000572005, 000572005
Electric Wire, and Power and Distribution Equipment | Batteries, Nonrechargeable
Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
---|---|---|---|
61 | 01 JAN 1961 | 00-057-2005 | 35499 ( BATTERY, NONRECHARGEABLE ) |
Cross Reference | NSN 6135-00-057-2005
Part Number | Cage Code | Manufacturer |
---|---|---|
15B | 80204 | AMERICAN NATIONAL STANDARDS INSTITUTE, INCORPORATED |
5156SC | 09823 | BURGESS INC |
6708 | 74025 | MARATHONNORCO AEROSPACE, INC. DBA MARATHON BATTERY |
708 | 06803 | NATIONAL ELECTRONIC DISTRIBUTORS |
708 | 77542 | SPECTRUM BRANDS, INC. |
778 | 83740 | EVEREADY BATTERY CO INC |
M708 | 90303 | DURACELL INC |
VS131 | 54590 | RCA CORP DISTRIBUTION AND SPECIAL PRODUCTS |
WB101 | 81348 | FEDERAL SPECIFICATIONS PROMULGATED BY GENERAL SERVICES |
Request a Quote
What Our Customers Say
Compare
NSNs for Compare ( up to 4 ): Add 6135-00-057-2005
Related Products | NSN 6135-00-057-2005
Technical Data | NSN 6135-00-057-2005
Characteristic | Specifications |
---|---|
VOLTAGE IN VOLTS | 22.5 |
TAP VOLTAGE IN VOLTS | -3.0 -4.5 -6.0 -9.0 -10.5 -16.5 |
SHAPE | RECTANGULAR |
TERMINAL QUANTITY | 8 |
TERMINAL TYPE | SPRING CLIP |
OVERALL WIDTH | 2.438 INCHES MAXIMUM |
OVERALL LENGTH | 4.000 INCHES MAXIMUM |
OVERALL HEIGHT | 3.125 INCHES MAXIMUM |
SPECIAL FEATURES | PACKED 4 PER PKG |
NONDEFINITIVE SPEC/STD DATA | 15B RADIO C TYPE AND N CLASS |
MANUFACTURERS CODE | 81348 |
NON-DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | WB101 |
Restrictions/Controls & Freight Information | NSN 6135-00-057-2005
Category | Code | Description |
---|---|---|
Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
Precious Metals Indicator Code: | U | Precious metal type is unknown |
Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
Category | Code | Description |
---|---|---|
No Freight Information |
