Product Details | UNINTERRUPTIBLE POWER SUPPLY

6130-01-548-3921 An item that provides continuous backup power to electronic devices in the event of a utility power dip or blackout. It generally contains a battery and a power inverter that provides the necessary backup power in the event of a loss of normal input utility power. It may also contain a power line filter or power line conditioning devices. Excludes power supplies without standby power, electrical power inverers, and batteries.

Part Alternates: APC BACK-UPS CS 650VA 230V, APCBACKUPSCS650VA230V, BACK-UPS CS 650VA 230V, BACKUPSCS650VA230V, BK650EI, 6130-01-548-3921, 01-548-3921, 6130015483921, 015483921

Electric Wire, and Power and Distribution Equipment | Converters, Electrical, Nonrotating

Supply Group (FSG) NSN Assign. NIIN
61 21 FEB 2007 01-548-3921

Demand History | NSN 6130-01-548-3921

Part Number Request Date QTY Origin
6130-01-548-3921 2021-09-264 50 US

Cross Reference | NSN 6130-01-548-3921

Part Number Cage Code Manufacturer
APC BACK-UPS CS 650VA 230V 0MG77 SCHNEIDER ELECTRIC IT CORPORATION DBA FOREIGN PARENT IS SCHNEIDER
BACK-UPS CS 650VA 230V 0MG77 SCHNEIDER ELECTRIC IT CORPORATION DBA FOREIGN PARENT IS SCHNEIDER
BK650EI 0MG77 SCHNEIDER ELECTRIC IT CORPORATION DBA FOREIGN PARENT IS SCHNEIDER
BK650EI AA326 ELETTRODATA SPA
BK650EI AC322 FO.RA.MIL. S.R.L.
BK650EI AC822 S.I.F.A. DEL DR. ANSALDO & C. SAS
BK650EI AD115 ROSATO FRANCESCO & C. SRL
BK650EI AD421 R1 SPA
BK650EI AE106 TECNOINFORMATICA SAS
BK650EI AF601 DIRECT PC SRL

Request a Quote

What Our Customers Say

Compare

NSNs for Compare ( up to 4 ): Add 6130-01-548-3921

Technical Data | NSN 6130-01-548-3921

Characteristic Specifications
OUTPUT VOLTAGE RATING 230.0 AC VOLTS NOMINAL SINGLE POWER OUTPUT
OUTPUT CURRENT RATING 650.0 AC VOLT-AMPERE NOMINAL SINGLE POWER OUTPUT
OUTPUT WATTAGE RATING 400.0 WATTS NOMINAL SINGLE POWER OUTPUT
INPUT VOLTAGE RATING 230.0 AC VOLTS NOMINAL SINGLE OPERATING POWER RQMT
INPUT FREQUENCY RATING 50.0 HERTZ MINIMUM AND 60.0 HERTZ MAXIMUM SINGLE OPERATING POWER RQMT
BATTERY FEATURE AND TYPE RECHARGEABLE LEAD ACID CELL
OVERALL LENGTH 11.180 INCHES NOMINAL
OVERALL WIDTH 3.580 INCHES NOMINAL
OVERALL HEIGHT 6.490 INCHES NOMINAL
OPERATING AMBIENT TEMP RANGE 0.0 TO 40.0 DEG CELSIUS

Restrictions/Controls & Freight Information | NSN 6130-01-548-3921

Category Code Description
Hazardous Material Indicator CodeNThere is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials
Demilitarization Code:ANon-Munitions List Item/ Non-Strategic List Item - Demilitarization not required.
Electro-static Discharge Susceptible:ANo known Electrostatic Discharge (ESD) or Electromagnetic Interference (EMI) sensitivity
Precious Metals Indicator Code:AItem does not contain precious metal
Criticality Code:X The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application.
Automatic Data Processing Equipment:0Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9)
Category Code Description
No Freight Information
