NSN 6130-00-264-6195 1263, 7402, CR7
Product Details | METALLIC RECTIFIER
6130-00-264-6195 An electrical item (the working element of which is constructed essentially of metallic substances) which changes alternating current to direct current by the rectifying action occurring at the junction interface between a metallic conductor and a semiconductor. Excludes sets of metallic rectifiers which are not rated for rectifying capabilities but are used as suppressors. For items containing germanium or silicon, see SEMICONDUCTOR DEVICE (1), DIODE; SEMICONDUCTOR DEVICE SET and RECTIFIER, SEMICONDUCTOR DEVICE. For a complete power supply utilizing metallic rectifiers, see POWER SUPPLY.
Part Alternates: 1263, 7402, CR7, 6130-00-264-6195, 00-264-6195, 6130002646195, 002646195
Electric Wire, and Power and Distribution Equipment | Converters, Electrical, Nonrotating
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 61 | 01 JAN 1963 | 00-264-6195 | 00299 ( RECTIFIER, METALLIC ) |
Drawings & Photos | NSN 6130-00-264-6195
Demand History | NSN 6130-00-264-6195
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 1263 | 2011-12-335 | 10 | United States |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 6130-00-264-6195
Technical Data | NSN 6130-00-264-6195
| Characteristic | Specifications |
|---|---|
| MATERIAL | SELENIUM |
| RMS INPUT MAXIMUM VOLTAGE RATING | 130.0 VOLTS |
| DC OUTPUT MAXIMUM CURRENT RATING | 65.000 MILLIAMPERES |
| LOAD TYPE | CAPACITIVE |
| DC OUTPUT MAXIMUM VOLTAGE RATING | NOT RATED |
| STACK QUANTITY | 1 |
| TEMP RATING | 85.0 DEG CELSIUS |
| ENVIRONMENTAL PROTECTION | MOISTURE |
| INCLOSURE FEATURE | UNENCLOSED |
| OVERALL WIDTH | 0.688 INCHES NOMINAL |
| OVERALL HEIGHT | 0.688 INCHES NOMINAL |
| STACK OVERALL LENGTH | 0.719 INCHES NOMINAL |
| TERMINAL QUANTITY | 2 |
| TERMINAL TYPE | SOLDER LUG |
| GROUNDED TERMINAL | NOT INCLUDED |
| MOUNTING METHOD | HOLES |
| MOUNTING CONFIGURATION | ONE 0.142 IN. MIN DIA HOLE THROUGH CENTER OF STACK |
Restrictions/Controls & Freight Information | NSN 6130-00-264-6195
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | B | Munitions List Item - Mutilation (MUT) to the point of scrap required. (Formerly: Demilitarization not required. Trade Security Controls (TSCs) required at disposition.) |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 062900 | RECTIFIERS NOI/BATTERY ELIMINATORS |
| Less than car load rating | ||
| Less than truck load rating | M | 85.0 |
| Water commodity Code | 658 | unknown |
| Originating Activity Code | XX | |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 6130-00-264-6195
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9G | Navy-owned stocks of defense general material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | S9G | Defense Supply Center Richmond Richmond, VA 23297 |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | Y | TERMINAL ITEM #(NON-STOCKED ITEMS) Future procurement is not authorized. No wholesale stock is available for issue. 1. Requisitions will not be processed to the wholesale manager. 2. Internal Service/agency requisitioning may be continued in accordance with the Service/agency requisitioning policies. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
