Product Details | ELECTRICAL-ELECTRONIC COMPONENT MOUNTING PAD
5999-00-250-2398 An item fabricated from electrically nonconductive material specifically designed to provide a support for mounting an electrical and/or an electronic component such as a semiconductor device, relay, or resistor into the next higher assembly. It isolates the component from the mounting surface of the next higher assembly, it may act as a strain relief to avoid damage to the component seal, and it may permit soldering of the component to the next higher assembly without damage. It includes holes, notches, or other provisions for physical alignment and spacing of electrical leads and/or other mounting facilities projecting from the component it mounts. It may also afford protection from shock or vibration. It may be either nonthermally conductive which protects the component from temperature changes in the next higher assembly or it may be thermally conductive which permits heat generated in the component to be drained out to a heat sink. For items whose function is electrical insulation only, see INSULATOR, (as modified). Excludes HOLDER, (as modified); RETAINER, (as modified), and SPACER, PLATE.
Part Alternates: ST25671, 11503955-1, 11568850, 1203209, 1203-209, 13043012, 33909210, 339092-10, 3451581, 345158-1, 10272DAP, 10272-DAP, 10549190, 8681770002, 868177-0002, 5999-00-250-2398, 00-250-2398, 5999002502398, 002502398, 115039551
Electrical and Electronic Equipment Components | Miscellaneous Electrical and Electronic Components
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 10 NOV 1969 | 00-250-2398 | 61934 ( MOUNTING PAD, ELECTRICAL-ELECTRONIC COMPONENT ) |
Drawings & Photos | NSN 5999-00-250-2398
Demand History | NSN 5999-00-250-2398
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 5999-00-250-2398 | 2016-12-343 | 55 | United States |
Cross Reference | NSN 5999-00-250-2398
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 10272-DAP | 07047 | ROSS MILTON CO THE |
| 10549190 | 19200 | US ARMY ARDEC RDECOM |
| 11503955-1 | 18876 | U S ARMY AVIATION AND MISSILE COMMAND |
| 11568850 | 18876 | U S ARMY AVIATION AND MISSILE COMMAND |
| 1203-209 | 72314 | BAE SYSTEMS INFORMATION AND ELECTRONIC SYSTEMS INTEGRATION I |
| 13043012 | 04939 | LOCKHEED MARTIN CORPORATION DBA LOCKHEED MARTIN |
| 13043012 | 18876 | U S ARMY AVIATION AND MISSILE COMMAND |
| 13043012 | 58260 | PROGRAM MANAGER ADVANCED ATTACK HELICOPTER BARCOM AMCPM-AAH |
| 339092-10 | 22915 | NORTHROP GRUMMAN CORP ELECTRONIC SYSTEMS DEFENSIVE SYSTEM |
| 345158-1 | 37695 | RAYTHEON COMPANY DBA RAYTHEON |
| 868177-0002 | 06481 | NORTHROP GRUMMAN SYSTEMS CORPORATION |
| 868177-0002 | 13973 | LITTON SYSTEMS INC. DIV NAVIGATION SYSTEMS DIVISION |
| ST25671 | K0967 | MBDA UK LTD |
