Product Details | BACKPLANE ASSEMBLY
5998-01-585-0469 An insulating panel upon which two or more CONNECTOR, RECEPTACLE, ELECTRICAL, are mounted, and completely processed electrical conductor paths are deposited, etched, or printed in various paths. It provides or completes a circuit between two or more CIRCUIT CARD ASSEMBLY or ELECTRONIC COMPONENTS ASSEMBLY. It may be designed for panel or chassis mounting, or for insertion into a CONNECTOR, RECEPTACLE, ELECTRICAL. Includes motherboards. For items containing processed electrical conductor paths and contacts for plug-in connecting facilities, see PRINTED WIRING BOARD. See also PRINTED CIRCUIT BOARD; CIRCUIT CARD ASSEMBLY and CABLE ASSEMBLY, PRINTED, FLEXIBLE.
Part Alternates: 6892026011, 689-2026-011, 5998-01-585-0469, 01-585-0469, 5998015850469, 015850469
Electrical and Electronic Equipment Components | Electrical and Electronic assemblies, Boards, Cards, and Associated Hardware
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 13 MAY 2010 | 01-585-0469 | 34736 ( BACKPLANE ASSEMBLY ) |
Cross Reference | NSN 5998-01-585-0469
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 689-2026-011 | 78711 | TELEPHONICS CORPORATION DBA COMMUNICATIONS SYSTEMS DIVISION |
