Product Details | INTERMEDIATE FREQUENCY AMPLIFIER
5996-00-845-8915 An electronic device whose input signals controls a local source of power and delivers an output signal of greater amplitude with respect to current and/or voltage. The output signals characteristics are uniformly related to the input signals. It is tuned to a single fixed frequency which is the resultant of heterodyne action between a local oscillator frequency and a signal frequency introduced from an external source.
Part Alternates: 546-6053-00, 5996-00-845-8915, 00-845-8915, 5996008458915, 546605300, 008458915
Electrical and Electronic Equipment Components | Amplifiers
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 01 JAN 1960 | 00-845-8915 | 00885 ( AMPLIFIER, INTERMEDIATE FREQUENCY ) |
Drawings & Photos | NSN 5996-00-845-8915
Demand History | NSN 5996-00-845-8915
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 546605300 | 2012-03-76 | 1 | Malaysia |
Cross Reference | NSN 5996-00-845-8915
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 546-6053-00 | 13499 | ROCKWELL COLLINS, INC. DBA GOVERNMENT SYSTEMS |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 5996-00-845-8915
Related Products | NSN 5996-00-845-8915
Technical Data | NSN 5996-00-845-8915
| Characteristic | Specifications |
|---|---|
| FREQUENCY PER CHANNEL | 499.0 KILOHERTZ NOMINAL OPERATING CHANNEL |
| SIGNAL VOLTAGE RATING PER CHANNEL | 4.500 VOLTS NOMINAL OUTPUT |
| OVERALL GAIN | 130.0 DECIBELS |
| IMPEDANCE RATING PER CHANNEL | 50.000 OHMS INPUT CHANNEL 300.000 OHMS OUTPUT CHANNEL |
| EXTERNAL DC OPERATING VOLTAGE IN VOLTS | 26.0 NOMINAL 1ST VOLTAGE 18.0 NOMINAL 2ND VOLTAGE 28.0 NOMINAL 3RD VOLTAGE |
| BASIC SHAPE STYLE | 1 RECTANGULAR OR SQUARE |
| OVERALL LENGTH | 4.375 INCHES NOMINAL |
| OVERALL HEIGHT | 3.000 INCHES NOMINAL |
| OVERALL WIDTH | 4.250 INCHES NOMINAL |
| MANUFACTURERS CODE | 13499 |
| DESIGN CONTROL REFERENCE | 546-6053-00 |
