NSN 5996-00-488-7060 10584, 00-488-7060, 004887060
Product Details | MAGNETIC AMPLIFIER
5996-00-488-7060 An item consisting of a saturable reactor which is specially designed to be used in conjunction with a rectifier(s) for amplification purposes. The rectifier(s) may or may not be an integral part of the item of supply. The item may include resistors, capacitors, and/or other electrical components.
Part Alternates: 10584, 5996-00-488-7060, 00-488-7060, 5996004887060, 004887060
Electrical and Electronic Equipment Components | Amplifiers
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 15 MAY 1970 | 00-488-7060 | 16193 ( AMPLIFIER, MAGNETIC ) |
Demand History | NSN 5996-00-488-7060
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 5996-00-488-7060 | 2018-10-295 | 1 | United States |
Cross Reference | NSN 5996-00-488-7060
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 10584 | 34401 | WEIGH-TRONIX INC |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 5996-00-488-7060
Related Products | NSN 5996-00-488-7060
Technical Data | NSN 5996-00-488-7060
| Characteristic | Specifications |
|---|---|
| TERMINAL TYPE AND QUANTITY | 7 WIRE LOOP AND 4 SOLDER STUD |
| WINDING OPERATING VOLTAGE | 8.00 DC VOLTS NOMINAL SINGLE COMPONENT 1ST CONTROL 4.00 DC VOLTS NOMINAL SINGLE COMPONENT 2ND CONTROL |
| WINDING FUNCTION AND QUANTITY | 2 PRIMARY AND 1 SECONDARY AND 2 CONTROL SINGLE COMPONENT |
| MOUNTING METHOD | THREADED STUD SINGLE GROUP |
| MOUNTING FACILITY QUANTITY | 4 SINGLE GROUP |
| THREAD SERIES DESIGNATOR | UNC SINGLE GROUP |
| NOMINAL THREAD SIZE | 0.312 INCHES SINGLE GROUP |
| THREAD QUANTITY PER INCH | 18 SINGLE GROUP |
| (NON-CORE DATA) THREAD CLASS | 2A SINGLE GROUP |
| (NON-CORE DATA) THREAD LENGTH | 0.719 INCHES NOMINAL SINGLE GROUP |
| (NON-CORE DATA) THREAD DIRECTION | RIGHT-HAND SINGLE GROUP |
| CENTER TO CENTER DISTANCE BETWEEN MOUNTING FACILITIES PARALLEL TO LENGTH | 6.625 INCHES NOMINAL SINGLE MOUNTING FACILITY SINGLE CENTER GROUP |
| CENTER TO CENTER DISTANCE BETWEEN MOUNTING FACILITIES PARALLEL TO WIDTH | 3.500 INCHES NOMINAL SINGLE MOUNTING FACILITY SINGLE CENTER GROUP |
| INCLOSURE TYPE | HERMETICALLY SEALED |
| BODY HEIGHT | 6.625 INCHES NOMINAL |
| OVERALL LENGTH | 10.625 INCHES NOMINAL |
| OVERALL HEIGHT | 7.375 INCHES NOMINAL |
| OVERALL WIDTH | 4.750 INCHES NOMINAL |
| RELIABILITY INDICATOR | NOT ESTABLISHED |
Restrictions/Controls & Freight Information | NSN 5996-00-488-7060
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | B | Munitions List Item - Mutilation (MUT) to the point of scrap required. (Formerly: Demilitarization not required. Trade Security Controls (TSCs) required at disposition.) |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 063035 | SETS RADIO/TV AND RELATED ARTICLES |
| Less than car load rating | ||
| Less than truck load rating | G | 125.0 |
| Water commodity Code | 758 | unknown |
| Originating Activity Code | TA | Sacramento Air Logistics Center McClellan AFB, CA 95652-5609 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 5996-00-488-7060
Air Force| Category | Code | Description |
|---|---|---|
| Budget Code | 9 | General Support DIV57X4921.070:Air Force decentrally managed expense items (ERRC XB3, XF-3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors. |
| Materiel Management Aggregation Code | EH | SX:ELECTRONIC COMPONENTS |
| Price Validation | N | The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
|
| Fund Code | SF | Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point. |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DF | Department of the Air Force |
| Service Organization | F | U.S. Air Force |
| Reparability | N | Stock Fund (except Munitions) |
| Acquisition Advice Codes | J | NOT STOCKED, CENTRALLY PROCURED # (NON-STOCKED ITEMS) IMM/Service centrally managed but not stocked item. Procurement will be initiated only after receipt of a requisition. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
